神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (08-004) - LINER & PISTON KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
237 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS03 | [1] | LINER & PISTON KIT(M0) | |
| . . | 6D22Z ALL | [1] | LINER & PISTON KIT(M0) | |
| 1-9. | VAME999511 | [3] | LINER KIT PISTON 2CYL 6D22 | LINER KIT PISTON 2CYL 6D22 |
| 1. | VAME051221 | [6] | LINER, ENGINE CYLIND | KOBCYL B SIZE Superseded by part number: 132313A1 |
| 2. | VAME051375 | [6] | O-RING | KOB Superseded by part number: VAME151038 |
| 3. | VA3090722300 | [6] | SEAL KIT | KOB Superseded by part number: 132311A1 |
| 4. | VA3110702401 | [12] | O-RING | KOB Superseded by part number: 3110702401 |
| 5. | VAME052590 | [6] | PISTON RING SET | KOBPISTON, B SIZE |
| 6. | VAME999170 | [6] | PISTON RING SET 1CYL | |
| 7. | VAME052149 | [6] | PIN | KOBPISTON Superseded by part number: 132468A1 |
| 8. | VA3121733100 | [12] | O-RING | KOB Superseded by part number: 132493A1 |
| . . | VAME052660 | [6] | BUSHING | KOB Superseded by part number: 132465A1 |
