神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (03-010) - FUEL HOSE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
708 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | M5:6D221CT-KS03 | [1] | FUEL HOSE(M5) | |
| . . | M2:6D221CZ-KS09 | [1] | FUEL HOSE(M2) | |
| . . | M2:6D221CZ-KS07 | [1] | FUEL HOSE(M2) | |
| . . | M2:6D221CZ-KS04 | [1] | FUEL HOSE(M2) | |
| . . | M2:6D221CZ-KS01 | [1] | FUEL HOSE(M2) | |
| . . | M6:6D221CT-KS06 | [1] | FUEL HOSE(M6) | |
| . . | M7:6D221CZ-KS0A | [1] | FUEL HOSE(M7) | |
| 1. | VAME910448 | [1] | FLEXIBLE HOSE | KOBI/P-FILTER L=480 (FOR M2) |
| . . | VAME910348 | [1] | HOSE | KOBL=480 (FOR M5 & M6) |
| . . | VAME910136 | [1] | FLEXIBLE HOSE | KOBL=360 (FOR M7) |
| 2. | VAME910144 | [1] | HOSE | KOBFUEL FEED, FILTER-I/P L=440 (FOR M2) |
| . . | VAME910152 | [1] | HOSE | KOBL=520 (FOR M5&M6) |
| . . | VAME910346 | [1] | HOSE | KOBL=460 (FOR M7) |
| . . | VAME930328 | [1] | STAY | KOB(FOR M2) |
| . . | VAME930243 | [1] | COUNTERWEIGHT (FOR M5 & M6) | COUNTERWEIGHT (FOR M5 & M6) |
| 4. | VAMH020807 | [2] | CLIP | KOB(FOR M2&M5&M6) |
| . . | VA3126101500 | [1] | CLAMP | KOB(FOR M7) Superseded by part number: 134803A1 |
| 5. | VAMF240023 | [1] | BOLT & WASHER ASSY 6X12 | BOLT & WASHER ASSY 6X12 |
| 6. | VAMF300841 | [1] | SCREW | KOBW/WSR 10X20 (FOR M5 & M6&M7) Superseded by part number: 132461A1 |
| 11. | VAMH037116 | [1] | FLEXIBLE JOINT | KOBSWIVELING D=10 (FOR M2&M5&M7) |
