神钢零件查询(6D22CT) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (01-004) - FLY WHEEL HOUSING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
537 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CZ-KS06 | [1] | FLY WHEEL HOUSING(M0) | |
| . . | 6D221CZ-KS09 | [1] | FLY WHEEL HOUSING(M0) | |
| . . | 6D221CZ-KS07 | [1] | FLY WHEEL HOUSING(M0) | |
| . . | 6D221CZ-KS04 | [1] | FLY WHEEL HOUSING(M0) | |
| . . | 6D221CZ-KS01 | [1] | FLY WHEEL HOUSING(M0) | |
| . . | 6D221CZ-KS03 | [1] | FLY WHEEL HOUSING(M0) | |
| . . | 6D221CZ-KS0A | [1] | FLY WHEEL HOUSING(M0) | |
| 1. | VAME052684 | [1] | HOUSING, F/W | |
| 2. | VA3091201400 | [1] | PLUG | KOBDUST Superseded by part number: 132428A1 |
| 2A. | VAM0001300 | [1] | PLUG | KOB |
| . . | VAMF660066 | [1] | GASKET | KOB16 Superseded by part number: VAF420216000 |
| 3. | VAMF300877 | [5] | BOLT | KOBW/WSR 12X65 |
| 4. | VAMF300882 | [8] | BOLT W/WSR 12X90 | BOLT W/WSR 12X90 |
| 6. | VA3121233300 | [1] | OIL SEAL | KOB Superseded by part number: 132459A1 |
| 7. | VAME052550 | [1] | RETAINER | KOBOILSEAL Superseded by part number: 132426A1 |
| 8. | VA3111203902 | [1] | O-RING | KOB Superseded by part number: 132432A1 |
| 9. | VA3092020100 | [1] | SLINGER | KOBOILSEAL Superseded by part number: 132456A1 |
| 11. | VAMF243649 | [4] | BOLT | KOBW/WSR 8X16 |
| 12. | VAME061699 | [1] | POINTER | KOBREAR Superseded by part number: 132414A1 |
| 13. | VAMF100031 | [1] | BOLT | KOB6X25 |
| . . | VAMF430004 | [1] | NUT | KOB6 Superseded by part number: 132434A1 |
| . . | VAMF450404 | [1] | WASHER | KOBSPG 6 Superseded by part number: 132427A1 |
| 14. | VA3121202300 | [1] | COVER | KOBPOINTER Superseded by part number: 132403A1 |
| 25. | VAME052661 | [1] | PLATE | KOBRE Superseded by part number: 132413A1 |
| 26. | NSS | [1] | NOT SOLD SEPARAT | CONGASKET, CASE-RE PLATE |
| . . | VAME052671 | [1] | GASKET | KOB Superseded by part number: 132407A1 |
| 27. | VAME052672 | [1] | GASKET | KOBREAR PLATE-F/W HOUSING Superseded by part number: 132409A1 |
| 28. | VAMF300866 | [9] | BOLT W/WSR 12X25 | BOLT W/WSR 12X25 |
