| 1. |
47517973
|
[1] |
PICK-UP
|
NH
Service, 1.8M with Assist Roll
|
| 2. |
578189
|
[12] |
FLANGE
|
NH
Superseded by part number: 86620026
|
| 3. |
84375530
|
[1] |
AUGER
|
NH
LH
|
| 4. |
84375560
|
[1] |
AUGER
|
NH
RH
|
| 5. |
84329282
|
[27] |
GUARD
|
NH
|
| 6. |
84297360
|
[27] |
DIVIDER
|
NH
|
| 7. |
84305031
|
[1] |
GUIDE
|
NH
RH
|
| 7. |
47847841
|
[1] |
GUARD
|
NH
RH
|
| 8. |
84305034
|
[1] |
GUIDE
|
NH
LH
|
| 8. |
47881435
|
[1] |
GUARD
|
NH
LH
|
| 9. |
47864510
|
[1] |
FLOOR,260mm W x 1150mm L x 6.35mm Thk, Polyurethane
|
NH
|
| 10. |
84522982
|
[1] |
FRAME
|
NH
1.8M Rotor Pickup
|
| 11. |
86594423
|
[6] |
BEARING,28.6mm Hex x 72mm OD x 25mm W
|
NH
Superseded by part number: 84330069
|
| 12. |
84297306
|
[1] |
SPROCKET
|
PLO
11T, RC60
|
| 13. |
87037892
|
[1] |
SPROCKET
|
PA
13T, RC50 Superseded by part number: 87641197
|
| 14. |
47447659
|
[8] |
SPACER,44 mm OD x 2mm Thk
|
NH
|
| 15. |
84281955
|
[2] |
ANGLE
|
PLO
|
| 16. |
87039762
|
[82] |
SELF-TAP SCREW,Hex Wash Hd, 5/16"-18 x 5/8"
|
PA
Superseded by part number: 570821
|
| 17. |
47470834
|
[1] |
ROLL
|
NH
Assist
|
| 18. |
9804256
|
[2] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 19. |
86633356
|
[6] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 20. |
9804278
|
[17] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
86050286
|
[24] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 22. |
86625115
|
[2] |
PIN,M6 x 40mm OAL
|
IMO
|
| 23. |
87577839
|
[34] |
SELF-TAP SCREW,Hex Washer Hd, 5/16" - 18 x 7/8"
|
SAS
|
| 24. |
84546571
|
[1] |
SPROCKET
|
PLO
19T, RC50
|
| 25. |
84404702
|
[27] |
DIVIDER
|
NH
|
| 26. |
84385890
|
[1] |
SHIELD
|
PLO
RH, Upper
|
| 27. |
84385892
|
[1] |
SHIELD
|
PLO
LH, Upper
|
| 28. |
88529
|
[2] |
LOCK PIN,5.56mm OD x 44.45mm L, Slotted
|
NH
|
| 29. |
84596266
|
[1] |
LINK
|
PLO
|
| 30. |
84558469
|
[1] |
PLATE
|
PLO
LH
|
| 31. |
47453913
|
[1] |
PLATE
|
PLO
RH
|
| 32. |
87020910
|
[1] |
SPACER,10.4mm ID x 19mm OD x 8.9mm Thk
|
PA
|
| 33. |
213404
|
[1] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
|
| 34. |
9804263
|
[1] |
BOLT,M10 x 49.2mm, Cl 8.8
|
NH
|
| 35. |
86610198
|
[2] |
INSERT,M6 x 1
|
NH
|
| 36. |
9804261
|
[13] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
