凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (60.220.CC[07]) - VAR - 726654 - 2.0M ROLLER WINDGUARD, USED WITHOUT TOP ASSIST ROLL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
956 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84488984
|
[1] |
ROLLER
|
NH
|
| 2. |
47361881
|
[2] |
ARM
|
NH
|
| 3. |
47362277
|
[1] |
WINDGUARD
|
NH
|
| 4. |
84426074
|
[2] |
ARM
|
NH
|
| 5. |
86603075
|
[2] |
FLANGE,Bearing, 52.01 mm ID x 95.3 mm OD x 8.7 mm
|
NH
|
| 6. |
325103
|
[2] |
BALL BEARING,25mm ID x 52mm OD x 15mm W
|
ZED
|
| 7. |
84238738
|
[2] |
SPACER,10.34mm ID x 15.88mm OD x 12mm L
|
NH
|
| 8. |
80702
|
[6] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 9. |
9804262
|
[2] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 10. |
9804278
|
[6] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 11. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 12. |
308761
|
[6] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 13. |
9804277
|
[6] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 14. |
80756
|
[2] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 15. |
197559
|
[2] |
CHAIN,9" L
|
NH
|
| 16. |
86508947
|
[2] |
LINCH PIN,18.8mm OD
|
NH
|
| 17. |
47507709
|
[2] |
SPACER,24.88mm ID x 41mm OD x 13mm Thk
|
PLO
|
| 18. |
47505113
|
[2] |
BEARING HOUSING
|
PLO
|
| 19. |
9637692
|
[2] |
NUT,3/8"-16, GB
|
NH
|
| 20. |
87027237
|
[2] |
CHAIN,18 Links x 37.2mm = 670mm L
|
PA
Superseded by part number: 87055684
|
| 21. |
88546
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5
|
NH
|
