凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (60.260.BL[10]) - OVERSHOT FEEDER ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
239 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84493781
|
[1] |
HOUSING
|
NH
Rotor
|
| 2. |
84494203
|
[1] |
FEEDER
|
NH
Rotor
|
| 3. |
84427232
|
[2] |
COVER
|
NH
|
| 4. |
47638589
|
[1] |
STRIPPER
|
PLO
RH
|
| 5. |
47638595
|
[1] |
STRIPPER
|
PLO
LH
|
| 6. |
84427552
|
[1] |
SHIELD
|
NH
|
| 7. |
84427228
|
[1] |
SHIELD
|
NH
|
| 8. |
84399287
|
[4] |
RING,82mm ID x 140mm OD x 1.98mm Thk
|
NH
|
| 9. |
86635012
|
[4] |
FLANGE
|
NH
|
| 10. |
84399284
|
[2] |
RING
|
NH
|
| 11. |
84419671
|
[2] |
PIVOT
|
NH
|
| 12. |
84324246
|
[2] |
SPHERICAL BEARING,31.75mm ID x 72mm OD x 25mm Thk
|
NH
|
| 13. |
47431597
|
[4] |
SPACER,Hex, 33mm ID x 45mm OD x 1.98mm Thk
|
NH
|
| 14. |
84427184
|
[1] |
SPACER,37.3mm ID x 45.3mm OD x 22.5mm Thk
|
PLO
|
| 15. |
87343
|
[2] |
LOCK PIN,6.35mm OD x 44.45mm L, Slotted
|
GI
|
| 16. |
84414114
|
[1] |
SUPPORT
|
NH
|
| 17. |
84427224
|
[1] |
SUPPORT
|
NH
|
| 18. |
9671714
|
[2] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 19. |
9804277
|
[6] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 20. |
308761
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 21. |
9804263
|
[12] |
BOLT,M10 x 49.2mm, Cl 8.8
|
NH
|
| 22. |
9804266
|
[2] |
BOLT,Hex, M12 x 25mm, Cl 8.8, Full Thd
|
DUB
|
| 23. |
9804261
|
[8] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 24. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 25. |
84495646
|
[1] |
AUGER
|
NH
LH
|
| 26. |
84495626
|
[1] |
AUGER
|
NH
RH
|
| 27. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
