神钢零件查询(6D22CT) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (06-007[01]) - EXHAUST PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
664 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CZ-KS06 | [1] | EXHAUST PIPE(M3) | |
| . . | 6D221CZ-KS09 | [1] | EXHAUST PIPE(M3) | |
| . . | 6D221CZ-KS07 | [1] | EXHAUST PIPE(M3) | |
| . . | 6D221CZ-KS04 | [1] | EXHAUST PIPE(M2) | |
| . . | 6D221CZ-KS01 | [1] | EXHAUST PIPE(M2) | |
| . . | 6D221CT-KS03 | [1] | EXHAUST PIPE(M4) | |
| 2. | VAME058621 | [1] | PIPE | KOB(FOR M2&M3) |
| . . | VAME058716 | [1] | PIPE | KOB(FOR M4) |
| 3. | VAME063737 | [1] | GASKET | KOB(FOR M2&M3) |
| 4. | VAMH000181 | [4] | BOLT 12X83 (FOR M2&M3) | BOLT 12X83 (FOR M2&M3) |
| . . | VAMF450007 | [4] | WASHER | KOBPLAIN 12 (FOR M2&M3) Superseded by part number: 132624A1 |
| 5. | VAME920000 | [4] | SPACER | KOBL=40 (FOR M2&M3) |
| 6. | VAMH004073 | [4] | NUT | KOBFLANGE 12 (FOR M2&M3) |
| 7. | VAMF407003 | [2] | STUD | KOB10X18 (FOR M4) |
| 8. | VAMH004054 | [2] | NUT | KOBFLANGE 10 (FOR M4) Superseded by part number: 134868A1 |
| 9. | VAME058767 | [1] | BRACKET | KOB |
| 10. | VAME058769 | [1] | BRACKET | KOBMUFFLER |
| 11. | VAMF300883 | [3] | BOLT | KOBW/WSR 12X100 |
| 12. | VAMF130589 | [2] | BOLT | KOB12X30 |
| . . | VAMF450407 | [2] | WASHER SPG 12 | WASHER SPG 12 |
| 12A. | VAMF241278 | [3] | BOLT | KOBW/WSR 10X16 |
| . . | VAMF450006 | [3] | NUT | KOBPLAIN 10 Superseded by part number: 133247A1 |
| 13. | VA3093293200 | [2] | SCREW | KOBU-BOLT |
| 14. | VAMF430006 | [8] | NUT | KOB10 Superseded by part number: VAF230510000 |
| . . | VAMF450406 | [4] | WASHER | KOBSPG 10 |
| 15-16. | VAME068372 | [1] | CLAMP | KOBSEAL ASSY (FOR M3) |
| 15. | VA3093290800 | [1] | CLAMP | KOBEXH PIPE (FOR M2) |
| . . | VAME068373 | [1] | CLAMP | KOB(FOR M3) Superseded by part number: VAME068372 |
| . . | VA1226653100 | [1] | CLAMP | KOB(FOR M4) |
| 16. | VAMF100089 | [2] | BOLT 10X35 (FOR M2) | BOLT 10X35 (FOR M2) |
| . . | VAMF101314 | [2] | SCREW | KOB12X35 (FOR M3) Superseded by part number: VAF103512035 |
| . . | VAMF101312 | [1] | SCREW | KOB12X30 (FOR M4) |
| . . | VAMF430006 | [2] | NUT | KOB10 (FOR M2) Superseded by part number: VAF230510000 |
| . . | VAMF430007 | [2] | NUT | KOB12 (FOR M3) |
