| 1. |
84582052
|
[1] |
ARM
|
NH
Fixed Roll
|
| 2. |
84582051
|
[1] |
ARM
|
NH
Starter Roll
|
| 3. |
86633971
|
[2] |
BOLT,M12 x 1.75 x 377.5mm L
|
NH
|
| 4. |
84401598
|
[2] |
SPROCKET,39.967mm ID x 118.4mm OD x 14.61mm Thk
|
GI
13T RC80, Incl 26 Superseded by part number: 87011880
|
| 5. |
86637258
|
[3] |
TUBE,19.05 mm OD x 228.60 mm L
|
NH
|
| 6. |
86643093
|
[2] |
INDICATOR
|
NH
|
| 7. |
86618710
|
[3] |
SPRING,1-3/8" OD x 8-5/8" L
|
NH
|
| 8. |
45455
|
[2] |
SPACER,13.5mm ID x 25.4mm OD x 9.5mm Thk
|
NH
|
| 9. |
84376806
|
[1] |
SPACER,13mm ID x 31.75mm OD x 32.5mm L
|
PLO
|
| 10. |
84582099
|
[1] |
ARM
|
NH
|
| 11. |
47395966
|
[1] |
SPROCKET,RC60, 13T
|
NH
Double Idler, 13T RC60
|
| 12. |
47388340
|
[1] |
TENSIONER
|
NH
|
| 13. |
46710
|
[1] |
SPACER,16.27mm ID x 25.48mm OD x 11.1mm Thk
|
NNA
Superseded by part number: 86529376, 86529376, NLS
|
| 14. |
142656
|
[5] |
WASHER,33.35mm ID x 47.63mm OD x 3.43mm Thk
|
NH
|
| 15. |
87365
|
[8] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 16. |
80700
|
[9] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 17. |
86000441
|
[3] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 18. |
9706685
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 19. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 20. |
120046
|
[1] |
CARRIAGE BOLT,M16 x 60mm, Cl 8.8
|
ZED
Superseded by part number: 87552612
|
| 21. |
120090
|
[1] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 22. |
300389
|
[2] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 23. |
120049
|
[1] |
CARRIAGE BOLT,Short Nk, M16 x 90mm, Cl 8.8
|
NH
|
| 24. |
9804270
|
[1] |
BOLT,Hex, M12 x 60mm, Cl 8.8
|
NH
|
| 25. |
87400
|
[1] |
COTTER PIN,3/16" x 2"
|
WIN
|
| 26. |
66553
|
[2] |
BALL BEARING,16.13mm ID x 40mm OD x 12.12mm W
|
NH
|
