凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (62.140.AR[03]) - BALE DENSITY TAKE UP ARM AND ROLLERS, DRY HAY, YGN193203 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
880 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47689488
|
[1] |
ARM
|
NH
Take Up
|
| 2. |
84356720
|
[1] |
ROLL,88.9mm OD x 1142mm L
|
PLO
Front Serpentine, Incl 8
|
| 3. |
84601406
|
[1] |
ROLL
|
PLO
Rear Serpentine, Incl 9
|
| 4. |
86516321
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87654791
|
| 5. |
9823372
|
[1] |
SHAFT,1135mm L
|
NH
Incl 10
|
| 6. |
86516322
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87654792
|
| 7. |
47945176
|
[2] |
BOLT
|
PLO
|
| 8. |
84259867
|
[2] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
PLO
|
| 9. |
47935418
|
[2] |
BEARING HOUSING
|
NH
Incl 8
|
| 10. |
130045
|
[2] |
PIN,5mm OD x 26mm L, Slotted
|
NH
|
