凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (68.170.AM[03]) - NET WRAP STATIONARY ROLL BRAKE TENSIONER MOUNTING PARTS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
993 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47506043
|
[1] |
SHIELD
|
NH
|
| 2. |
47506044
|
[1] |
SHIELD
|
NH
|
| 3. |
86624184
|
[2] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 4. |
86511842
|
[1] |
BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8
|
NH
|
| 5. |
80664
|
[2] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 6. |
9804279
|
[2] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 7. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 8. |
80577826
|
[1] |
WASHER,8.7mm ID x 34.93mm OD x 1.94mm Thk
|
NH
|
