神钢零件查询(6D24-TEB) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (05-004) - EXHAUST PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
964 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 13010. | VAME063680 | [1] | GASKET | KOBEXHAUST PIPE, 9809.1- |
| 13087. | VAMF450007 | [4] | WASHER | KOBEXHAUST PIPE, PLAIN,12, 9809.1- Superseded by part number: 132624A1 |
| 13091. | VAME920000 | [4] | SPACER | KOBEXHAUST PIPE, T=40, 9809.1- |
| 13096. | VAMH004073 | [4] | NUT | KOBEXHAUST PIPE, SELF LOCKING,FLANGE.12, 9809.1- |
| 13099. | VAMH000679 | [4] | SCREW | KOBEXHAUST PIPE, 12X85, 9809.1- |
| 13156. | VA1286637500 | [1] | FLANGE EXHAUST PIPE CONNECTING, 9809.1- | FLANGE EXHAUST PIPE CONNECTING, 9809.1- |
