凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (88.100.35[06]) - DIA KIT, SPLITTER VALVE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
474 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84468885
|
[1] |
DIA KIT, HARVESTER
|
PLO
Splitter Valve, Incl 2 - 13
|
| 2. |
84394625
|
[1] |
INSTRUCTION
|
PLO
|
| 3. |
84476761
|
[1] |
WIRE HARNESS
|
PLO
|
| 4. |
76344
|
[5] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
Inc 14
|
| 5. |
84474353
|
[2] |
HYDRAULIC HOSE
|
PLO
381 mm Long
|
| 6. |
330346
|
[1] |
45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
|
NH
Inc 14
|
| 7. |
80701
|
[2] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 8. |
328873
|
[2] |
BOLT,Hex, M6 x 1 x 120mm, Cl 8.8, Full Thd
|
PA
|
| 9. |
646223
|
[6] |
STRAP,8.0" L
|
PA
Superseded by part number: 95874S
|
| 10. |
86512555
|
[2] |
NUT,M16 x 2, Cl 10
|
FOR
|
| 11. |
87016318
|
[2] |
VALVE
|
PA
Splitter
|
| 12. |
84474365
|
[1] |
MOUNT
|
PLO
|
| 13. |
86629586
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 Fem Sw
|
NH
|
| 14. |
9617873
|
[2] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
| 16. |
47608545
|
[1] |
MOUNT
|
PLO
|
| 17. |
9706694
|
[2] |
NUT,Hex, M20, Cl 8
|
ZED
|
