神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-020 ) - BREATHER & OIL FILLER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
214 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4. | VAME088117 | [1] | BREATHER | KOBHOSE,BREATHER |
| 4B. | VAME081547 | [1] | PIPE | KOBPIPE,BREATHER |
| 5. | VAMS660170 | [2] | HOSE CLIP | KOBCLIP,HOSE, 26 |
| 13. | VAMH000706 | [1] | SCREW | KOBBOLT,FLANGE 10 X16 Superseded by part number: 132289A1 |
| 15. | VAME011913 | [1] | HOSE | KOBHOSE,BREATHER L=4 00 Superseded by part number: VAME088703 |
| 16. | VAMS660170 | [1] | HOSE CLIP | KOBCLIP HOSE, 26 |
