纽荷兰零件查询(D150C XLT) - CRAWLER DOZER - TIER 4A (10/13-) (88.100.37[01]) - DIA, DRAWBAR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
927 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47569404 | [1] | KIT | BURDIA, Drawbar |
| 2. | 47569459 | [1] | INSTRUCTION | BUR |
| 3. | 47496414 | [1] | DRAWBAR | BUR |
| 4. | 896-11024 | [8] | WASHER,26mm ID x 44mm OD x 5mm Thk | IH Superseded by part number: 87016608 |
| 5. | 87564731 | [8] | BOLT,Hex, M24 x 80mm, Cl 10.9 | BUR |
| 6. | 87339515 | [1] | PIN | BUR |
| 7. | A30338 | [1] | PIN | CAS Superseded by part number: 270184 |
| 8. | 47496260 | [2] | SLEEVE | BUR |
| 9. | 47496259 | [1] | CABLE,405mm L | BUR |
