凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (88.100.60[02]) - DIA KIT, GATHERING WHEEL ARM ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
505 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84557067
|
[1] |
ARM
|
PA
RH Superseded by part number: 47507669
|
| 1. |
84557060
|
[1] |
ARM
|
PA
LH Superseded by part number: 47507673
|
| 2. |
796762
|
[1] |
DISC
|
PA
Incl 4 Superseded by part number: 86636746
|
| 3. |
200734
|
[1] |
HUB CAP
|
NH
|
| 4. |
132709
|
[2] |
BEARING CUP,50.29mm OD x 10.67mm W
|
NH
|
| 5. |
132710
|
[2] |
BEARING CONE,25.4mm ID x 14.73mm W
|
NH
|
| 6. |
136736
|
[1] |
SEAL
|
PA
Superseded by part number: 80136736, 740061
|
| 7. |
26301
|
[1] |
WASHER
|
NH
|
| 8. |
603373
|
[1] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Slotted Superseded by part number: 143183
|
| 9. |
87398
|
[1] |
COTTER PIN,3/16" OD x 1-1/4" OAL
|
NH
|
