纽荷兰零件查询(D150C XLT) - CRAWLER DOZER - TIER 4A (10/13-) (88.100.55[02]) - LEICA READY KIT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
436 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47677960 | [1] | KIT | BURDIA Leica Ready, Incl 2 - 16 |
| 2. | 47677963 | [1] | INSTRUCTION | BUR |
| 3. | 47408769 | [1] | BRACKET | BURLeica DZ Mast |
| 4. | 47408804 | [1] | BRACKET | BURLeica DZ Slope Sensor |
| 5. | 47692472 | [1] | WIRE HARNESS | BURLeica Ready |
| 6. | 87423314 | [2] | GROMMET,1.5" ID x 2.125" ID x 0.562" Thk | EML |
| 7. | L11541 | [2] | CABLE TIE,203.2mm L, Nylon | CAS Superseded by part number: 87000312 |
| 8. | L18331 | [10] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
| 9. | 47408806 | [1] | BRACKET | BURLeica DZ Display Post |
| 10. | 47408796 | [1] | BRACKET | BURLeica DZ Display Arm |
| 11. | 47693937 | [1] | MODULE | BURLeica Cradle |
| 12. | 47424058 | [1] | BRACKET | BURLeica DZ Controller |
| 13. | 47693912 | [1] | WIRE HARNESS | BURInterface |
| 14. | 47466116 | [1] | MODULE | BURJunction Box |
| 15. | 47551349 | [1] | WIRE HARNESS | BUR1M Display |
| 16. | 47481723 | [1] | ELEC CONNECTOR | BURCan Splitter |
