| 1. | 47524794 | [1] | KIT | BURRipper Superseded by part number: 47636792 |
| 2. | 47525053 | [1] | INSTRUCTION | BUR |
| 3. | 201-101 | [4] | HYD CONNECTOR,11/16"-16 ORFS x 9/16"-18 ORB | CAS Superseded by part number: 9993143 |
| 4. | 201-113 | [2] | HYD CONNECTOR,13/16"-16 ORFS x 1 5/16"-12 ORB | CAS |
| 5. | 201-903 | [2] | TUBE NUT,Blkhd, 13/16"-16 | CAS |
| 6. | 214-31112 | [2] | HOSE CLAMP,6-1/4" - 7-1/8", HD Worm | CAS Superseded by part number: 87530426 |
| 7. | 219-1 | [6] | LUBE NIPPLE,1/8"-27 x .66 lg | CAS Superseded by part number: 80710 |
| 8. | 219-55 | [2] | LUBE NIPPLE,90º, 1/8" NPT x .84" lg | CAS Superseded by part number: 80719 |
| 9. | 614-6020 | [2] | BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 120100 |
| 10. | 627-16025 | [3] | BOLT,Hex, M16 x 2 x 25mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86639032 |
| 11. | 627-16040 | [2] | BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 374835 |
| 12. | 814-10070 | [1] | BOLT,Hex, M10 x 1.5 x 70mm, Cl 8.8 | CAS Superseded by part number: 43144 |
| 13. | 827-10050 | [2] | BOLT,Hex, M10 x 1.5 x 50mm, Cl 10.9 | CAS Superseded by part number: 43249 |
| 14. | 827-12130 | [4] | BOLT,Hex, M12 x 1.75 x 130mm, Cl 10.9 | FAR Superseded by part number: 9847703 |
| 15. | 827-16180 | [4] | BOLT,Hex, M16 x 2 x 180mm, Cl 10.9 | CAS Superseded by part number: 9840670 |
| 16. | 827-8060 | [2] | BOLT,Hex, M8 x 1.25 x 60mm, Cl 10.9 | CAS Superseded by part number: 86625005 |
| 17. | 832-41412 | [8] | NUT,M12 x 1.75, Cl 10 | WIC Superseded by part number: 412672 |
| 18. | 832-41416 | [8] | NUT,M16 x 2, Cl 10 | CAS Superseded by part number: 86512555 |
| 19. | 895-11006 | [2] | WASHER,M6 x 12mm OD x 1.6mm | CAS Superseded by part number: 86588450 |
| 20. | 43248 | [1] | BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9 | NH |
| 21. | 43263 | [1] | BOLT,Hex, M12 x 1.75 x 60mm, Cl 10.9 | BAS |
| 22. | 337476 | [4] | BOLT,Hex, M12 x 1.75 x 50mm, Cl 10.9 | WIN |
| 23. | 412398 | [6] | BOLT,Hex, M16 x 2 x 50mm, Cl 10.9, Full Thd | NH |
| 24. | 8475948 | [1] | NUT,M10 x 1.5, Cl 8 | BER Superseded by part number: 100037 |
| 25. | 9991973 | [1] | ELBOW | BAS |
| 26. | 13311217 | [4] | SCREW,Pozidriv Oval Hd, Csk, M5 x 20mm, Cl 5.8, Full Thd | IMO |
| 27. | 16104121 | [2] | NUT,M8 x 1.25, Cl 10 | LEC Superseded by part number: 17152821 |
| 28. | 47369789 | [2] | HYDRAULIC HOSE,9.53mm ID x 1340mm L, SAE 100R16 | BUR |
| 29. | 47369792 | [2] | HYDRAULIC HOSE,9.53mm ID x 615mm L, SAE 100R16 | BUR |
| 30. | 47427400 | [2] | PIN,70mm OD x 274mm L | BUR |
| 31. | 84420672 | [1] | HYDRAULIC CYLINDER,Double Acting, 69.9mm Rod, 597.7mm Stroke | BUR Superseded by part number: 47458145 |
| 31. | 84420672R | [1] | REMAN-HYD CYLINDER | BUR |
| 31. | 84420672C | [1] | CORE-HYD CYLINDER | BURReturn Number |
| 32. | 47496259 | [1] | CABLE,405mm L | BUR |
| 33. | 47496260 | [2] | SLEEVE | BUR |
| 34. | 47496495 | [1] | KIT | BURRipper Parts |
| 35. | 47516491 | [1] | TUBE | BURRipper Cylinder Tube End |
| 36. | 47517705 | [2] | CLAMP | BUR |
| 37. | 47518240 | [1] | PROTECTIVE SLEEVE | BUR |
| 38. | 47519074 | [1] | HOSE,12.7mm ID x 1597mm L, SAE 100R16 | BUR |
| 39. | 84241398 | [4] | PIN,50.77mm OD x 194mm L | BUR |
| 40. | 84241399 | [4] | PIN,70.02mm OD x 229mm L | BUR |
| 41. | 84322203 | [1] | CLIP | BUR |
| 42. | 84399654 | [1] | JOYSTICK | BUR |
| 43. | 84402706 | [1] | PLATE | BUR |
| 44. | 84402707 | [1] | PLATE | BUR |
| 45. | 84406410 | [1] | BRACKET | BUR |
| 46. | 84420571 | [1] | SPACER,13.51mm ID x 19.05mm OD x 20mm L | BUR |
| 47. | 84428520 | [1] | MOUNT | BUR |
| 48. | 84510460 | [2] | STEP | BUR |
| 49. | 84545982 | [1] | BRACKET | BUR |
| 50. | 84545985 | [1] | BRACKET | BUR |
| 51. | 85802820 | [1] | CHECK VALVE | IMO |
| 52. | 86639079 | [2] | ELBOW,90º, 13/16"-16, ORFS, Blkhd | FAR |
| 53. | 87302487 | [1] | SPACER,13.8mm ID x 21.3mm OD x 10.3mm L | WIC |
| 54. | 87339515 | [1] | PIN | BUR |
| 55. | 87354794 | [16] | BOLT,Hex, M24 x 60mm, Cl 10.9 | BUR |
| 56. | 87383798 | [3] | PIN,50.8mm OD x 139.7mm L | BUR |
| 57. | 87417721 | [2] | THREADED INSERT,M10 x 1.5-6H x 29 L | BUR |
| 58. | 87591918 | [1] | 90 ELBOW | GI |
| 59. | 87655042 | [4] | SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk | BUR |
| 60. | 87655043 | [4] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BUR |
| 61. | 87655044 | [6] | SPECIAL WASHER,17.75mm ID x 31.50mm OD x 4.20mm, HTS Boron, ZNM | BUR |
| 62. | 87655046 | [1] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 63. | 87687101 | [2] | WASHER,10.65mm ID x 31mm OD x 3.3mm Thk | IMO |
| 64. | 155588C1 | [1] | SPACER,3/8" X-Strng Pipe x 2" | IH |
| 65. | 336371A1 | [2] | PIN | CAS |
| 66. | 405737A2 | [2] | SQUARE NUT | BUR |
| 67. | 419041A1 | [2] | SPACER | BUR |
| 68. | 419223A1 | [5] | WASHER | BUR |
| 69. | 434130A1 | [2] | HOSE CLAMP | BUR |
| 70. | A30338 | [1] | PIN | CAS Superseded by part number: 270184 |
| 71. | L302731 | [1] | CLAMP | CAS |
