凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (88.100.62[12]) - DIA KIT, TAILGATE CHOPPING ROLL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
404 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47877606
|
[1] |
DIA KIT, HARVESTER
|
PLO
Tailgate Chopping Roll, Incl 2 - 17
|
| 2. |
47933765
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
47512226
|
[1] |
ROLL
|
PLO
Tailgate Chopping, Incl 18
|
| 4. |
9823372
|
[1] |
SHAFT,1135mm L
|
NH
Incl 20
|
| 5. |
87654792
|
[2] |
SUPPORT
|
PLO
|
| 6. |
47871214
|
[1] |
BRACKET
|
PLO
LH
|
| 7. |
47876349
|
[1] |
BRACKET
|
PLO
RH
|
| 8. |
47876890
|
[2] |
PLATE
|
PLO
|
| 9. |
47876893
|
[2] |
PLATE
|
PLO
|
| 9. |
47876894
|
[2] |
PLATE
|
PLO
|
| 10. |
374894
|
[6] |
CARRIAGE BOLT,Sq Nk, M10 x 70mm, Cl 8.8
|
ZED
Superseded by part number: 811-10070
|
| 11. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 12. |
9804278
|
[6] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 13. |
140046
|
[10] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 14. |
337563
|
[2] |
BOLT,M12 x 1.75 x 47.68mm, Cl 10.9
|
NH
|
| 15. |
86629541
|
[8] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 16. |
47876969
|
[2] |
SHIELD
|
PLO
|
| 17. |
412085
|
[2] |
BOLT,Hex, M12 x 1.75 x 80mm, Cl 10.9
|
NH
|
| 18. |
47504953
|
[2] |
BEARING HOUSING,73mm ID x 106.1mm OD x 30mm Thk
|
NH
Incl 19
|
| 19. |
9845576
|
[2] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
NH
Superseded by part number: 84330072
|
| 20. |
130045
|
[2] |
PIN,5mm OD x 26mm L, Slotted
|
NH
|
