纽荷兰零件查询(D150C XLT) - CRAWLER DOZER - TIER 4A (10/13-) (90.150.BJ[01]) - GUARD, BRUSH, SWEEP New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
280 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84549084 | [2] | CHANNEL | BUR |
| 2. | 47519291 | [1] | GUARD | BUR |
| 3. | 47519289 | [1] | GUARD | BUR |
| 4. | 47519293 | [1] | TUBE | BUR |
| 5. | R40721 | [4] | GROMMET | CAS |
| 6. | R40954 | [2] | BUSHING | CAS |
| 7. | 827-16100 | [2] | BOLT,Hex, M16 x 2 x 100mm, Cl 10.9 | CAS Superseded by part number: 86541970 |
| 8. | 832-10416 | [2] | NUT,M16 x 2, Cl 8 | CAS Superseded by part number: 412066 |
| 9. | 896-15020 | [2] | WASHER,22mm ID x 44mm OD x 5mm Thk | CAS Superseded by part number: 86639847 |
| 10. | 627-20055 | [2] | BOLT,Hex, M20 x 2.5 x 55mm, Cl 10.9, Full Thd | CAS Superseded by part number: 190003809441 |
| 11. | 84390078 | [2] | MOUNT | BUR |
| 12. | R29799 | [2] | SHOCK ABSORBER | CAS |
| 13. | 87655043 | [2] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BUR |
| 14. | 814-12060 | [2] | BOLT,Hex, M12 x 1.75 x 60mm, Cl 8.8 | CAS Superseded by part number: 9706693 |
| 15. | D25022 | [2] | WASHER | CAS |
| 16. | 832-10412 | [2] | NUT,M12 x 1.75, Cl 8 | CAS Superseded by part number: 87780366, 412126 |
| 17. | 374835 | [4] | BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd | BHB |
| 18. | 47386675 | [2] | MOUNTING PLATE | BUR |
