凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (90.105.BH[05]) - RH, DOOR MOUNTING Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
614 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Door, RH
|
| 2. |
48058532
|
[1] |
|
HINGE
|
| 3. |
48058534
|
[1] |
|
BRACKET
|
| 4. |
47387253
|
[2] |
GAS STRUT
|
NH
|
| 5. |
86628347
|
[2] |
STUD,M8 x 36.5mm OAL, 10mm OD Ball
|
NH
|
| 6. |
47561233
|
[1] |
BRACKET
|
NH
|
| 7. |
87688487
|
[1] |
LATCH ASSY.
|
GI
|
| 8. |
86050286
|
[2] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 9. |
86511841
|
[3] |
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 10. |
9804261
|
[4] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 11. |
9804278
|
[9] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
86511842
|
[1] |
BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8
|
NH
|
| 13. |
86619801
|
[3] |
FLANGE NUT,M8 x 1.25, Cl 8
|
PA
Superseded by part number: 87681210
|
| 14. |
86507486
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 15. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 16. |
128104
|
[1] |
BUMPER
|
NH
|
| 17. |
47419756
|
[1] |
BRACKET
|
PLO
|
| 18. |
80701
|
[1] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 19. |
84517258
|
[1] |
MAGNET
|
ZED
Superseded by part number: 84579586
|
| 20. |
47482855
|
[1] |
SHIELD
|
NH
RH
|
| 21. |
322355
|
[1] |
BELLEVILLE WASHER,M4 Bolt Size x 10mm OD x 0.9mm Thk
|
NH
|
| 22. |
87896
|
[1] |
|
BLOCK
|
| 23. |
88576
|
[1] |
BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5
|
NH
|
| 24. |
86521610
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
NH
|
