| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 47441524 | [1] | SHIELD | NH Rear |
| 2. | 47376514 | [1] | SHIELD | NH Lower |
| 3. | 308761 | [10] | CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8 | NH |
| 4. | 322358 | [10] | BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk | NH |
| 5. | 9804277 | [10] | FLANGE NUT,Hex, M8 x 1.25, Cl 8 | NH Superseded by part number: 86505868 |
