现代零件查询R55W-7 QUICK CLAMP ASSY(CLOSE TYPE)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
408 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31M8-75020
|
[1] |
QUICK CLAMP ASSY
|
|
| 1. |
XKBN-00039
|
[1] |
BODY ASSY
|
|
| 1. |
XKBN-00363
|
[1] |
BODY ASSY
|
|
| 1. |
XKBN-00611
|
[1] |
BODY ASSY
|
|
| 2. |
XKBN-00040
|
[1] |
HITCH ASSY
|
|
| 2. |
XKBN-00608
|
[1] |
HITCH ASSY
|
|
| 3. |
XKBN-00041
|
[1] |
CYLINDER ASSY
|
|
| 3. |
XKBN-00356
|
[1] |
CYLINDER ASSY
|
|
| 3. |
XKBN-00542
|
[1] |
CYLINDER ASSY
|
|
| 3. |
XKBN-00609
|
[1] |
CYLINDER ASSY
|
|
| 3-1. |
XKBN-00057
|
[1] |
TUBE
|
|
| 3-1. |
XKBN-00546
|
[1] |
TUBE
|
|
| 3-2. |
XKBN-00058
|
[1] |
ROD
|
|
| 3-2. |
XKBN-00547
|
[1] |
ROD
|
|
| 3-2. |
XKBN-00618
|
[1] |
ROD
|
|
| 3-3. |
XKBN-00020
|
[1] |
PISTON
|
|
| 3-4. |
XKBN-00021
|
[1] |
COVER-ROD
|
|
| 3-4. |
XKBN-00548
|
[1] |
COVER-ROD
|
|
| 3-5. |
XKBN-00023
|
[1] |
NUT-NYLON
|
|
| 3-6. |
XKBN-00026
|
[1] |
VALVE-CHECK
|
|
| 3-7. |
XKBN-00027
|
[1] |
BEARING-OILLESS
|
|
| 3-8. |
XKBN-00028
|
[2] |
BUSHING-DU
|
|
| 3-9. |
XKBN-00009
|
[1] |
NIPPLE-GREASE
|
|
| 3-9. |
XKBN-00009
|
[2] |
NIPPLE-GREASE
|
|
| 3-10. |
XKBN-00029
|
[1] |
SEAL-COMPACT
|
|
| 3-11. |
XKBN-00030
|
[1] |
U-PACKING
|
|
| 3-11. |
XKBN-00550
|
[1] |
U-PACKING
|
|
| 3-12. |
XKBN-00031
|
[1] |
RING-BACK UP
|
|
| 3-13. |
XKBN-00032
|
[1] |
SEAL-DUST
|
|
| 3-13. |
XKBN-00549
|
[1] |
SEAL-DUST
|
|
| 3-14. |
XKBN-00033
|
[1] |
BUSHING-DU
|
|
| 3-15. |
XKBN-00034
|
[1] |
O-RING
|
|
| 3-16. |
XKBN-00035
|
[1] |
RING-BACK UP
|
|
| 3-17. |
XKBN-00036
|
[1] |
O-RING
|
|
| 3-18. |
XKBN-00037
|
[1] |
O-RING
|
|
| 3-19. |
XKBN-00059
|
[1] |
PLUG-PT
|
|
| 3-20. |
XKBN-00545
|
[1] |
CYLINDER SEAL KIT
|
|
| 3-14. |
XKBN-00033
|
[1] |
BUSH-DU
|
|
| 3-15. |
XKBN-00034
|
[1] |
O-RING
|
|
| 3-16. |
XKBN-00035
|
[1] |
RING-BACK UP
|
|
| 3-17. |
XKBN-00036
|
[1] |
O-RING
|
|
| 3-18. |
XKBN-00037
|
[1] |
O-RING
|
|
| 3-19. |
XKBN-00059
|
[1] |
PLUG-PT
|
|
| 4. |
XKBN-00042
|
[1] |
PIN-SAFETY
|
|
| 5. |
XKBN-00043
|
[1] |
PIN-SNAP
|
|
| 6. |
XKBN-00060
|
[1] |
WIRE ASSY
|
|
| 7. |
XKBN-00045
|
[1] |
PIN-HITCH
|
|
| 7. |
XKBN-00358
|
[1] |
PIN-HITCH
|
|
| 7. |
XKBN-00390
|
[1] |
PIN-HITCH
|
|
| 8. |
XKBN-00061
|
[2] |
BOLT-HEX
|
|
| 8. |
XKBN-00359
|
[2] |
BOLT-HEX
|
|
| 8. |
XKBN-00359
|
[1] |
BOLT-HEX
|
|
| N9. |
XKBN-00047
|
[2] |
BUSHING-HITCH
|
|
| 9. |
XKBN-00360
|
[2] |
BUSHING-HITCH
|
|
| 10. |
XKBN-00048
|
[1] |
PIN-FRAME
|
|
| 11. |
XKBN-00049
|
[1] |
PIN-CYLINDER
|
|
| 11. |
XKBN-00392
|
[1] |
PIN-CYLINDER
|
|
| 11. |
XKBN-00610
|
[1] |
PIN-CYLINDER
|
|
| 12. |
XKBN-00050
|
[1] |
RING-SNAP
|
|
| 12. |
XKBN-00336
|
[1] |
RING-SNAP
|
|
| 15. |
XKBN-00062
|
[2] |
PIN-BRACKET
|
|
| 16. |
XKBN-00063
|
[2] |
BOLT-HEX
|
|
| 16. |
XKBN-00362
|
[2] |
BOLT-HEX
|
|
| 17. |
XKBN-00064
|
[4] |
NUT-HEX
|
|
| 18. |
XKBN-00055
|
[2] |
HOSE ASSY-0X0
|
|
| 19. |
XKBN-00056
|
[2] |
ELBOW-90
|
|
| 20. |
XKBN-00009
|
[4] |
NIPPLE-GREASE
|
|
| 21. |
XKBN-00065
|
[2] |
WASHER-SPRING
|
|
| 21. |
XKBN-00065
|
[1] |
WASHER-SPRING
|
|
| 22. |
XKBN-00066
|
[1] |
NAMER PLATE
|
|
| 23. |
XKBN-00109
|
[2] |
RING-SNAP
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
