现代零件查询R55W-7 LOWER HYDRAULIC PIPING 1(#0269-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
145 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
LOWER HYD PIPING 1
|
|
| 13. |
P923-065018
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 14. |
P923-065026
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 15. |
P933-045006
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 16. |
P933-045008
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 24. |
31M8-41060
|
[1] |
CLAMP-HOSE
|
|
| 27. |
X500-110001
|
[2] |
CONNECTOR-ORFS
|
|
| 28. |
X500-110002
|
[1] |
CONNECTOR-ORFS
|
|
| 31. |
X520-210001
|
[2] |
ELBOW-90,ORFS
|
|
| 32. |
X500-220003
|
[1] |
CONNECTOR-ORFS
|
|
| 33. |
X500-220006
|
[2] |
CONNECTOR-ORFS
|
|
| 33. |
31M9-41260
|
[2] |
CONNECTOR
|
|
| 41. |
X850-525200
|
[2] |
ELBOW-90,SWIVEL,ORFS
|
|
| 42. |
X530-110002
|
[2] |
ELBOW-45,ORFS
|
|
| 45. |
S621-011001
|
[8] |
O-RING
|
|
| 46. |
S621-012001
|
[12] |
O-RING
|
|
| 49. |
S631-011004
|
[2] |
O-RING
|
|
| 50. |
S631-014004
|
[5] |
O-RING
|
|
| 53. |
Y161-014001
|
[8] |
O-RING
|
|
| 56. |
P392-180000
|
[2] |
WASHER-COPPER
|
|
| 61. |
S037-102022
|
[2] |
BOLT-W/WASHER
|
|
| 70. |
S551-050203
|
[10] |
CLAMP-BAND
|
|
| 71. |
P913-042013
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 72. |
P913-042014
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 74. |
S760-061410
|
[2] |
GROMMET
|
|
| 75. |
S760-061414
|
[2] |
GROMMET
|
|
| 76. |
31EK-11130
|
[2] |
COUPLING-SCREW
|
|
| 77. |
P913-065029
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 78. |
P923-065014
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 79. |
31M8-41210
|
[2] |
CROSS
|
|
| 80. |
X500-210002
|
[2] |
CONNECTOR-ORFS
|
|
| 81. |
P392-140000
|
[1] |
WASHER-COPPER
|
|
| 82. |
P220-110103
|
[1] |
PLUG-HEX
|
|
| 83. |
X820-065252
|
[1] |
TEE-R/TYPE,ORFS
|
|
