现代零件查询R55W-7 LOWER HYDRAULIC PIPING 2(#0269-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
685 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
LOWER HYD PIPING 2
|
|
| 4. |
31M6-03010
|
[1] |
VALVE-LOCKING
|
|
| 7. |
31M8-41011
|
[1] |
PIPE ASSY
|
|
| 8. |
31M8-41021
|
[1] |
PIPE ASSY
|
|
| 10. |
P923-042018
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 11. |
P923-042029
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 17. |
P933-082014
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 18. |
P933-082022
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 20. |
31M8-41110
|
[1] |
BRACKET-T/JOINT
|
|
| 22. |
31M8-41040
|
[1] |
CLAMP-HOSE
|
|
| 23. |
31M8-41050
|
[1] |
CLAMP-HOSE
|
|
| 25. |
31M5-03131
|
[2] |
COVER
|
|
| 27. |
X500-110001
|
[2] |
CONNECTOR-ORFS
|
|
| 28. |
X500-110002
|
[2] |
CONNECTOR-ORFS
|
|
| 29. |
X500-110003
|
[1] |
CONNECTOR-ORFS
|
|
| 29. |
X500-110003
|
[2] |
CONNECTOR-ORFS
|
|
| 30. |
X500-110013
|
[1] |
CONNECTOR-ORFS
|
|
| 34. |
X500-220007
|
[1] |
CONNECTOR-ORFS
|
|
| 37. |
X520-110002
|
[2] |
ELBOW-90,ORFS
|
|
| 38. |
X520-110003
|
[1] |
ELBOW-90,ORFS
|
|
| 39. |
31M8-41080
|
[1] |
ELBOW-90
|
|
| 43. |
X840-535153
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 45. |
S621-011001
|
[4] |
O-RING(SEAL LOCK TYPE)
|
|
| 46. |
S621-012001
|
[4] |
O-RING(SEAL LOCK TYPE)
|
|
| 47. |
S621-014001
|
[5] |
O-RING(SEAL LOCK TYPE)
|
|
| 49. |
S631-011004
|
[2] |
O-RING
|
|
| 50. |
S631-014004
|
[5] |
O-RING
|
|
| 51. |
S631-018004
|
[2] |
O-RING
|
|
| 51. |
S631-018004
|
[3] |
O-RING
|
|
| 56. |
P392-180000
|
[1] |
WASHER-COPPER
|
|
| 56. |
P392-180000
|
[2] |
WASHER-COPPER
|
|
| 58. |
S017-120452
|
[4] |
BOLT-HEXAGON HEAD
|
|
| 60. |
S017-160352
|
[4] |
BOLT-HEX
|
|
| 61. |
S037-102022
|
[4] |
BOLT-W/WASHER
|
|
| 62. |
S037-123022
|
[4] |
BOLT-W/WASHER
|
|
| 63. |
S037-123522
|
[4] |
BOLT-W/WASHER
|
|
| 64. |
S109-080856
|
[2] |
BOLT-SOCKET
|
|
| 67. |
S411-080002
|
[2] |
WASHER-SPRING
|
|
| 68. |
S411-120002
|
[4] |
WASHER-SPRING
|
|
| 69. |
S411-160002
|
[4] |
WASHER-SPRING
|
|
