神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE - MD200BLC EXCAVATORS (1/06-12/06) (03-001) - FUEL INJECTION PUMP GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
237 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-4. | VAME088300 | [1] | INJECTION PUMP GENERAL ASSY, FOR M4 ONLY | |
| 1-4. | VAME088294 | [1] | INJECTION PUMP GENERAL ASSY, FOR M7 ONLY | |
| 2. | VAME716691 | [1] | A TYPE, FOR M7 ONLY | |
| 2. | VAME723020 | [1] | GOVERNOR ASSY RSV TYPE, FOR M4 ONLY | |
| . . | VAME723423 | [1] | GOVERNOR RS TYPE, FOR M7 ONLY | GOVERNOR RS TYPE, FOR M7 ONLY |
| 3. | VAME717184 | [1] | FUEL FEED PUMP ASSY | |
| 4. | VAME723275 | [1] | TIMER | KOBFOR M4 ONLY |
| . . | VAME723506 | [1] | COUPLING ASSY, FOR M7 ONLY | |
| 5. | VAME705392 | [2] | BOLT, FOR M4 ONLY | |
| 6. | VAME705211 | [1] | BOLT | KOBBOLT, FOR M4 ONLY |
| 16. | VAMF520423 | [1] | O-RING | KOBO-RING 135 Superseded by part number: VAF315313500 |
| 17. | VAME088152 | [1] | U-BRACKET | KOBBRACKET, I/P A Superseded by part number: VAME088445 |
| 19. | VAMH000711 | [2] | SCREW | KOBBOLT, FLANGE 10 X 40 Superseded by part number: 135146A1 |
| 20. | VA3127516500 | [2] | SPACER | KOBSPACER |
| 21. | VAMF140268 | [1] | BOLT | KOBBOLT, FLANGE 10 X 25 |
| 22. | VAMF434105 | [1] | NUT | KOBNUT, FLANGE 10 |
| 25. | VAMH037116 | [1] | FLEXIBLE JOINT | KOBJOINT, SWIVEL |
