凯斯零件查询(RB554) - CASE IH ROUND BALER (7/07-1/14) (11.15) - WHEELS & TIRES, STANDARD PICKUP, 4 PLY, 16.5 X 6.5 - 8 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
473 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87056325
|
[1] |
SUPPORT ASSY.
|
PA
Bracket
|
| 2. |
86611228
|
[1] |
SPACER
|
PA
|
| 3. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Tire & Wheel
|
| 4. |
86616348
|
[1] |
WHEEL
|
NH
|
| 5. |
136376
|
[1] |
SEAL,31.75mm ID x 50.42mm OD x 6.75mm Thk
|
NH
Oil
|
| 6. |
572564R1
|
[2] |
BEARING CUP
|
IH
Tapered Roller Superseded by part number: 132709
|
| 7. |
D29266
|
[2] |
ROLLER BEARING,1" ID x 0.58"
|
CAS
Tapered Roller Superseded by part number: 132710
|
| 8. |
26130
|
[1] |
WASHER,26mm ID x 35mm OD x 1.7mm Thk
|
NH
Special, .060" Thk
|
| 9. |
603373
|
[1] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Jam, G2, 1"-14 Superseded by part number: 143183
|
| 10. |
432-1220
|
[1] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
Superseded by part number: 87398
|
| 11. |
200734
|
[1] |
HUB CAP
|
NH
|
| 12. |
279538
|
[1] |
TUBE
|
NH
Inner, 15 x 6 - 6
|
| 13. |
86611311
|
[1] |
TYRE/TIRE
|
PA
15 x 6 -6 Rib, 4 Ply
|
| 14. |
219-10
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: NH80715
|
