神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-023) - BREATHER AND OIL FILLER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
689 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME008160 | [1] | BREATHER | KOB |
| 3. | VAMH035072 | [1] | PACKING | KOBO-RING |
| 4. | VAME058897 | [1] | HOSE | KOBL=1250 |
| 9. | VAMS660170 | [1] | HOSE CLIP | KOBCLAMP,HOSE 26 |
| 11. | VAME001187 | [1] | GASKET | KOB |
| 12. | VAMH000529 | [2] | BOLT, SEAL 8X20 (FOR M4 ONLY) | |
| 12. | VAMH000530 | [1] | BOLT, SEAL 8X30 (FOR M7 ONLY) | |
| 13. | VAME008632 | [1] | FILLER, OIL | |
| 14. | VAMD008784 | [1] | CAP | KOBOIL FILLER Superseded by part number: VA1250A015 |
| 15. | VAME930095 | [1] | STAY | KOBSTAY (FOR M7 ONLY) |
| 16. | VAMH005006 | [1] | WASHER | KOBWASHER 8 T=2.6 (FOR M7 ONLY) Superseded by part number: VAMH005027 |
