约翰迪尔零件查询745 ATT - ATTACHMENTS ENGINE MOUNTING PLATE F045006 11 38 T0947 [T0947]EPC John Deere online
广数供应链运营团队, 14 02月, 2025，浏览：
902 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
F047863
|
[1] |
Plate
|
|
| 1. |
F054506
|
[1] |
Plate
|
|
| 2. |
F047864
|
[1] |
Cover
|
|
| 3. |
F047865
|
[1] |
Plate
|
|
| 3. |
F052781
|
[1] |
Plate
|
|
| 4. |
F003518
|
[3] |
Screw
|
|
| 5. |
F003470
|
[4] |
Screw
|
|
| 7. |
F047866
|
[2] |
Clutch
|
|
| 8. |
F047834
|
[1] |
Hydraulic Motor
|
|
| 9. |
F047867
|
[2] |
STOP SCREW
|
|
| 10. |
F047868
|
[1] |
Hose Clamp
|
|
| 11. |
F047869
|
[1] |
Hose
|
|
| 12. |
F047870
|
[1] |
Bracket
|
|
| 13. |
F027813
|
[2] |
Lock Nut
|
|
| 14. |
F059482
|
[1] |
SEAL RING
|
|
