| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 363-4122 | [1] | GASKET | |
| 2. | 376-9843 | [1] | TANK AS-FUEL | |
| 167-2307 | [1] | SEAL-U-CUP | ||
| 3. | [1] | PLATE | ||
| 4. | [1] | PLATE | ||
| 5. | [1] | PLATE | ||
| 6. | 259-4598 | [1] | SEAL-O-RING | |
| 7. | 8T-4199M | [6] | BOLT(M8X1.25X12-MM) | |
| 8. | 8T-4200M | [6] | BOLT(M8X1.25X16-MM) | |
| 9. | 8T-4224 | [12] | WASHER-HARD(8.8X16X2-MM THK) | |
| 10. | 8T-4970M | [6] | BOLT(M6X1X14-MM) | |
| 11. | 9X-8256 | [6] | WASHER(6.6X12X2-MM THK) | |
| M | METRIC PART | |||
