神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (06-003) - AIR CLEANER (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
506 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-10. | VAME008416 | [1] | AIRCLEANER ASSY 8 INCH (INNER PARTS) | AIRCLEANER ASSY 8 INCH (INNER PARTS) |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY, A/CLNR |
| 3. | VA3083081800 | [1] | AIR FILTER | KOBELEMENT, A/CLNR OUTER Superseded by part number: 2451R124-3A |
| 4. | VA3083081900 | [1] | AIR FILTER | KOBELEMENT, A/CLNR INNER Superseded by part number: 2451R124-3B |
| 5. | VA3083033300 | [2] | NUT | KOBNUT |
| 6. | VA3083033600 | [1] | CAMSHAFT | KOBCLAMP, A/CLNR |
| 7. | VA3083033400 | [1] | BAFFLE | KOBSCARF, BAFFLE |
| 8. | VAME008417 | [1] | CUP | KOBA/CLNR |
| 8. | VAME027203 | [1] | PLATE, CAUTION | |
| 9. | VA3123022400 | [1] | INDICATOR, DUST 762 | |
| 10. | VA3123069500 | [1] | HYDRAULIC VALVE | KOBVALVE, VACUUATOR |
