神钢零件查询(8DC8) - MITSUBISHI DIESEL ENGINE - K914 & K975 (1/79-12/06) (01-004) - FLYWHEEL HOUSING 020-160A Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
610 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME061337 | [1] | HOUSING,F/W | |
| 9. | VA3091201400 | [1] | PLUG | KOBPLUG,DUST Superseded by part number: 132428A1 |
| 10. | VAME062493 | [1] | PLATE,RE | |
| 11. | VA3121273101 | [1] | GASKET GASKET,CASE-RE PLATE | GASKET GASKET,CASE-RE PLATE |
| 12. | VA3121273201 | [1] | GASKET | KOBGASKET,RE PLATE-F/W HOUSING |
| 13. | VAMF300841 | [1] | SCREW | KOBBOLT, W/WSR 10X20 Superseded by part number: 132461A1 |
| 14. | VAMF300877 | [11] | BOLT | KOBBOLT, W/WSR 12X65 |
| 15. | VAMF300874 | [4] | BOLT,W/WSR 12X50 (FOR M0, M3 ONLY) | |
| 15. | VAMF300875 | [2] | BOLT.W/WSR 12X55 (FOR M1 ONLY) | |
| 15. | VAMF303401 | [2] | BOLT,W/WSR 12X85 (FOR M4 ONLY) | |
| 16. | VAME061699 | [1] | POINTER | KOBPOINTER,RE Superseded by part number: 132414A1 |
| 17. | VAMF100031 | [1] | BOLT | KOBBOLT 6X25 |
| . . | VAMF430004 | [1] | NUT | KOBNUT 6 Superseded by part number: 132434A1 |
| . . | VAMF450404 | [1] | WASHER | KOBWASHER,SPG 6 Superseded by part number: 132427A1 |
| 20. | VA3121202300 | [1] | COVER | KOBCOVER,POINTER Superseded by part number: 132403A1 |
| 23. | VAME052550 | [1] | RETAINER | KOBRETAINER,OILSEAL, Start Year: 01-NOV-84 Superseded by part number: 132426A1 |
| 23. | VAME061697 | [1] | RETAINER | KOBRETAINER,OILSEAL, Start Year: 01-OCT-84 Superseded by part number: 132426A1 |
| 24. | VA3111203902 | [1] | O-RING | KOBO-RING Superseded by part number: 132432A1 |
| 25. | VA3121233300 | [1] | OIL SEAL | KOBOILSEAL Superseded by part number: 132459A1 |
| 26. | VA3122034100 | [1] | SLINGER | KOBSLINGER,OILSEAL |
| 28. | VAMF243649 | [4] | BOLT | KOBBOLT,W/WSR 8X16, Start Year: 01-NOV-84 |
| 32. | VA3121204100 | [1] | SPACER L=42.55 (FOR M4 ONLY) | |
| 33. | VAMF300856 | [12] | BOLT B0LT,W/WSR 10X75 (FOR M4 ONLY) | BOLT B0LT,W/WSR 10X75 (FOR M4 ONLY) |
