约翰迪尔零件查询745 ATT - ATTACHMENTS ENGINE LUBRICATION SYSTEM F045006 11 90 TF1669 [TF1669]EPC John Deere online
广数供应链运营团队, 14 02月, 2025，浏览：
682 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
F058838
|
[1] |
Pump
|
|
| 1. |
F058839
|
[1] |
Filter
|
|
| 2. |
F058840
|
[1] |
CONNECTION
|
|
| 3. |
F058841
|
[1] |
Check Valve
|
|
| 4. |
F011057
|
[1] |
ELBOW NIPPLE
|
|
| 5. |
F056046
|
[1] |
O-Ring
|
|
| 6. |
F058842
|
[1] |
HOSE-ASSY
|
|
| 7. |
F058843
|
[1] |
Bushing
|
|
| 8. |
F058844
|
[1] |
Bushing
|
|
| 9. |
F025813
|
[1] |
ELBOW NIPPLE
|
|
| 10. |
F058845
|
[1] |
O-Ring
|
|
| 11. |
F005634
|
[1] |
O-Ring
|
|
| 12. |
F058846
|
[1] |
Housing
|
|
| 13. |
F058847
|
[1] |
Set Screw
|
|
| 14. |
F114468
|
[1] |
O-Ring
|
|
| 15. |
F047316
|
[1] |
Ball
|
|
| 16. |
F058848
|
[1] |
Spring
|
|
| 17. |
F030026
|
[1] |
Set Screw
|
|
| 18. |
F010726
|
[4] |
Screw
|
|
| 19. |
F058849
|
[1] |
Check Valve
|
|
| 20. |
F008355
|
[1] |
Strainer
|
|
| 21. |
F058850
|
[1] |
Spring
|
|
| 22. |
F005170
|
[1] |
SEAL RING
|
|
| 23. |
F058851
|
[1] |
NIPPLE
|
|
