神钢零件查询(8DC8) - MITSUBISHI DIESEL ENGINE - K914 & K975 (1/79-12/06) (01-022) - TURBO CHARGER (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
776 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-27. | VAME069878 | [1] | TURBO,ASSY TURBOCHARGER ASSY 4LF 602 | TURBO,ASSY TURBOCHARGER ASSY 4LF 602 |
| 1. | VAME719235 | [1] | COVER,COMPR | |
| 2. | VAME719144 | [1] | NUT,LOCK | |
| 3. | VAME719216 | [1] | WHEEL,COMPR 4LF 602 | |
| 4. | VAME719126 | [1] | RING RING,SNAP | RING RING,SNAP |
| 5. | VAME719124 | [1] | INSERT | |
| 6. | VAME719127 | [3] | O-RING | KOBO-RING |
| 7. | VAME719018 | [2] | RING,PISTON | |
| 8. | VAME719145 | [1] | SLEEVE,FLINGER | |
| 9. | VAME719129 | [1] | DEFLECTOR,OIL | |
| 10. | VAME719141 | [2] | RING,THRUST | |
| 11. | VAME719142 | [1] | SLEEVE,SPACER | |
| 12. | VAME719121 | [1] | BEARING,THRUST | |
| 13. | VAME719125 | [4] | RING,SNAP | |
| 14. | VAME719120 | [2] | BEARING | |
| 15. | VAME719122 | [1] | SLEEVE,OIL CONTROL | |
| 16. | VAME719157 | [1] | V-CLAMP ASSY | |
| 18. | VAME719156 | [1] | O-RING | |
| 19. | VAME719128 | [1] | BEARING HOUSING & PIN ASSY | |
| 20. | VAME719159 | [1] | PLATE,NAME | |
| 21. | VAME719043 | [2] | SCREW,SELF TAPPING | |
| 22. | VAME719207 | [1] | PLATE,TURBIN BACK | |
| 24. | VAME719271 | [1] | RING,PISTON | |
| 25. | VAME719213 | [1] | SHAFT & TURBIN WHEEL ASSY | |
| 26. | VAME719101 | [1] | V-CLAMP ASSY | |
| 27. | VAME719187 | [1] | TURBINE HOUSING ASSY 38CM2 | |
