神钢零件查询(8DC8) - MITSUBISHI DIESEL ENGINE - K914 & K975 (1/79-12/06) (01-028) - ENGINE HANGER 020-490A Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
582 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME040253 | [3] | HANGER, Start Year: 01-MAR-86 | |
| . . | VAME040253 | [4] | , Years: -01-FEB-86 | |
| 5. | VA3120164500 | [1] | COVER,WATER OUTLET LH (F0R M0, M1, M2, M3, M4, M5, M6 ONLY) | |
| . . | VAME097029 | [1] | LH (FOR M7 ONLY), Start Year: 01-JAN-86 | |
| . . | VAME060641 | [1] | LH (FOR M7 ONLY), Years: -01-DEC-85 | |
| . . | VAME061884 | [1] | LH (FOR M8 ONLY) | |
| 6. | VA3120164500 | [1] | COVER,WATER OUTLET RH (FOR M0, M1, M7 ONLY) | |
| . . | VAME061858 | [1] | RH (FOR M2, M3 ONLY), Start Year: 01-JAN-86 | |
| . . | VAME061900 | [1] | RH (FOR M2, M3 ONLY), Years: -01-DEC-85 | |
| . . | VAME097010 | [1] | RH (FOR M7 ONLY), Start Year: 01-JAN-86 | |
| . . | VAME060638 | [1] | RH (FOR M7 ONLY), Years: -01-DEC-85 | |
| 7. | VA3114641100 | [2] | GASKET | KOBGASKET Superseded by part number: VAME095018 |
| 10. | VAMF300841 | [8] | SCREW | KOBBOLT,W/WSR 10X20 (FOR M0, M2, M4, M7 ONLY) Superseded by part number: 132461A1 |
| . . | VAMF300843 | [3] | SCREW | KOBBOLT,W/WSR 10X25 (FOR M6 ONLY) Superseded by part number: 133250A1 |
| . . | VAMF300845 | [1] | BOLT | KOBBOLT,W/WSR 10X30 (FOR M6 ONLY) |
| . . | VAMF300842 | [1] | BOLT BOLT,W/WSR 10X22 (FOR M8 ONLY) | BOLT BOLT,W/WSR 10X22 (FOR M8 ONLY) |
| 11. | VAMS666224 | [2] | PLUG | KOBPLUG,TAPER PT3/4 (FOR M7 ONLY) |
