凯斯零件查询(RB564) - CASE IH ROUND BALER (7/07-1/14) (08.57) - SHIELDS, BALE COMMAND™, TWINE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
459 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 4. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Electric Twine Wrap
|
| 5. |
87048341
|
[1] |
SHIELD
|
PA
|
| 8. |
87515841
|
[1] |
LOAD DECK
|
PA
|
| 12. |
86643976
|
[1] |
ANTI-SKID STRIP
|
NH
Safety, 4" x 56"
|
| 19. |
844-8020
|
[4] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 20. |
811-8020
|
[5] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 23. |
322358
|
[14] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 27. |
9804277
|
[14] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 37. |
87014359
|
[1] |
DOOR ASSY.
|
PA
Includes: Decals
|
| 38. |
86511841
|
[7] |
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
|
NH
|
