神钢零件查询(8DC8) - MITSUBISHI DIESEL ENGINE - K914 & K975 (1/79-12/06) (02-005) - WATER TEMP GAUGE UNIT 030-160B Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
463 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3124618702 | [2] | PLUG | KOBPLUG (FOR M0, M2, M3, M6, M8 ONLY) Superseded by part number: 240292A1 |
| 3. | VA3089080401 | [1] | GAUGE | KOBUNIT,WATER TEMP 50-120C (FOR M0, M1, M2, M3 ONLY) Superseded by part number: 134836A1 |
| . . | VAMC850067 | [2] | 50-110C (FOR M5 ONLY) | |
| . . | VAME049146 | [1] | SENDER UNIT | KOB50-115C (FOR M8 ONLY) |
| 4. | VAME039860 | [1] | SWITCH,105.5 Degrees C | KOBSWITCH,THERMO 105C (FOR M2 ONLY) |
| 5. | VA3009839400 | [1] | BUZZER | KOBSWITCH,THERMO 98C (FOR M5, M8 ONLY)(FOR EMERGENCY) |
| 6. | VAMC880905 | [1] | TEMPERATURE SENDER | KOBSWITCH,OVER HEAT 100C (FOR M0 ONLY) |
| . . | VAMC880907 | [1] | CAP COVER | KOB110C (FOR M6 ONLY) Superseded by part number: VAMC856107 |
| 10. | VAME060211 | [1] | COCK | KOBCOCK,WATER Superseded by part number: VAME047603 |
