神钢零件查询(8DC8) - MITSUBISHI DIESEL ENGINE - K914 & K975 (1/79-12/06) (02-012) - OIL PRESS. SW & GAUGE UNIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
383 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAMH037725 | [3] | PLUG,TAPER PT1/8, Start Year: 01-JUN-84 | |
| . . | VAMH037237 | [3] | PLUG | KOB, Years: -01-MAY-84 |
| 2. | VAMS666220 | [3] | PLUG | KOBPLUG,TAPER PT1/8 (FOR M1, M2, M4, M9 ONLY), Start Year: 01-JUN-84 |
| . . | VAMH037135 | [3] | PLUG (FOR M1, M2, M4, M9 ONLY), Years: -01-MAY-84 | PLUG (FOR M1, M2, M4, M9 ONLY), Years: -01-MAY-84 |
| 5. | VAMH037491 | [1] | HYD CONNECTOR | KOBCONNECTOR PT1/4-PT1/8X2 (FOR M1, M2, M4, M5 ONLY) |
| 6. | VA642458002 | [1] | JOINT PT1/4-PT1/8 (FOR M9 ONLY) | |
| 10. | VAMC850069 | [1] | OIL SEPARATOR | KOBUNIT,OIL PRESS (FOR M1, M2 ONLY) |
| 11. | VA3089080700 | [1] | DIPSTICK | KOBUNIT,OIL PRESS (FOR M4 ONLY) |
| 15. | VAME951943 | [1] | SWITCH | KOBSWITCH,OIL PRESS 0.7KG/CM2 (FOR M1 ONLY)(FOR EMERGENCY) |
| . . | VAME951940 | [1] | SWITCH | KOB0.5KG/CM2 (FOR M2, M4, M5 ONLY) (FOR EMERGENCY) |
| . . | VAMC840219 | [1] | SWITCH | KOB0.5KG/CM2 (FOR M9 ONLY) Superseded by part number: H411892 |
| 21. | VAMC850070 | [1] | SWITCH | KOBUNIT,OIL TEMP (FOR M1 ONLY) |
