神钢零件查询(8DC8) - MITSUBISHI DIESEL ENGINE - K914 & K975 (1/79-12/06) (05-003) - CLUTCH COVER & DISC Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
898 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME550111 | [1] | CLUTCH DISC | KOBCLUTCH DISK CLUTCH DISC ASSY C12W43Z=14 (M0) Superseded by part number: VAME524342 |
| 1. | VAME550254 | [1] | CLUTCH DISC ASSY C12M41Z=14 (M5) | |
| 1. | VAME550213 | [1] | DISC | KOBCLUTCH DISC ASSY C12M41Z=14 (M9) Superseded by part number: VAME551124 |
| . . | VA4350147800 | [2] | FACING,C/L (FOR M0 ONLY) | |
| . . | VAME550195 | [12] | (FOR M5, M9 ONLY) | |
| . . | VAME550196 | [6] | (FOR M5, M9 ONLY) | |
| . . | VAME550164 | [36] | RIVET,FACING (FOR M0 ONLY) | |
| . . | VA4450146400 | [12] | FASTENER (FOR M5, M9 ONLY) | |
| . . | VAME520021 | [3] | (FOR M5, M9 ONLY) | |
| 2-20. | VAME550208 | [1] | PLATE | KOBPRESSURE PLATE & LEVER ASSY (FOR M0 ONLY) |
| 2-21. | VAME550248 | [1] | PRESSURE PLATE & LEVER ASSY (FOR M5 ONLY) | |
| 2-22. | VAME550226 | [1] | PRESSURE PLATE & LEVER ASSY (FOR M9 ONLY) | |
| 2. | VA4350238010 | [1] | CLUTCH COVER SUB ASSY | |
| 3. | VA4350230700 | [1] | PLATE,PRESS (FOR M0 ONLY) | |
| 3. | VA4350230900 | [1] | PLATE,PRESS (FOR M5, M9 ONLY) | |
| 4. | VA4350232700 | [12] | SPRING,PRESS (FOR M0, M9 ONLY) | |
| 4. | VAME550004 | [12] | SPRING,PRESS (FOR M5 ONLY) | |
| 6. | VA4350238200 | [12] | SEAT,SPG | |
| 7-15. | VAME550093 | [1] | KIT | KOBCLUTCH RELEASE SERVICE KIT (FOR M0 ONLY) Superseded by part number: VAME550904 |
| 7. | VAME550060 | [4] | RELEASE LEVER SUB ASSY | |
| 8. | VA4350243300 | [4] | PIN,RELEASE LEVER | |
| 9. | VA4350243300 | [4] | PIN,RELEASE LEVER (FOR M0 ONLY) | |
| 10. | VA4350243400 | [8] | WASHER,PLAIN | |
| 11. | VA4340213501 | [8] | PIN,COTTER | |
| 12. | VA4350237200 | [4] | SPRING,RETURN | |
| 14. | VA4350237100 | [4] | SUPPORT,RELEASE LEVER | |
| 15. | VA4340214301 | [4] | NUT,SUPPORT | |
| 16. | VA4340214101 | [4] | PLATE,LOCK | |
| 17. | VA4340206600 | [8] | BOLT,LOCK | |
| 18. | VA4350246200 | [4] | BOLT,STRAP | |
| . . | VAMF450407 | [4] | WASHER WASHER,SPG 12 | WASHER WASHER,SPG 12 |
| 19. | VA4350238100 | [4] | WASHER,STRAP SUPPORT | |
| 20. | VAME550209 | [8] | WASHER,STRAP PLATE | |
| 21. | VAMF300843 | [12] | SCREW | KOBBOLT, W/WSR 10X25 Superseded by part number: 133250A1 |
| 22. | VAME500090 | [1] | WASHER,ADJUSTING T = 1.2 | |
| 22. | VAME500091 | [1] | WASHER,ADJUSTING T = 2.3 | |
