| 1. |
87056380
|
[1] |
PICK-UP
|
PA
2M Wide & Stuffer Feeder Superseded by part number: 87605371
|
| 2. |
87042087
|
[1] |
PLATE
|
PA
, Serial Range: -Y9N043084 Superseded by part number: 87654729
|
| 2. |
84173517
|
[1] |
PLATE
|
NH
, Start Serial: Y9N043085
|
| 3. |
455102R21
|
[1] |
COLLAR
|
IH
Locking, Includes: Set Screw, Serial Range: -Y9N043084 Superseded by part number: 47577183
|
| 3. |
63266
|
[1] |
COLLAR,30.187mm ID x 44.83mm OD x 16.26mm W
|
GI
Locking, Includes: Set Screw, Start Serial: Y9N043085
|
| 4. |
214366C91
|
[1] |
BALL BEARING,25.40mm ID x 52mm OD
|
IH
, Serial Range: -Y9N043084 Superseded by part number: 204807C91
|
| 4. |
63265
|
[1] |
BALL BEARING,30.16mm ID x 62mm OD x 18mm W
|
GI
, Start Serial: Y9N043085
|
| 5. |
86603075
|
[2] |
FLANGE,Bearing, 52.01 mm ID x 95.3 mm OD x 8.7 mm
|
NH
Bearing, Serial Range: -Y9N043084
|
| 5. |
87758679
|
[2] |
FLANGED BEARING
|
PA
Bearing, Start Serial: Y9N043085 Superseded by part number: 87758678
|
| 6. |
86610143
|
[1] |
SPROCKET
|
NH
17T, RC 50, Standard Superseded by part number: 87047646
|
| 6. |
87055082
|
[1] |
SPROCKET
|
PA
18T, RC 50, Optional Superseded by part number: 87397995
|
| 6. |
87602188
|
[1] |
SPROCKET
|
NH
17T, No Set Screw Required
|
| 7. |
300483
|
[2] |
SET SCREW,M10 x 25mm
|
PA
|
| 8. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
2M Stuffer, Wide Pickup
|
| 10. |
86643381
|
[10] |
GUARD
|
NH
|
| 11. |
87055363
|
[21] |
GUARD ASSY.
|
PA
|
| 12. |
86640795
|
[1] |
SPACER,25.65mm ID x 31.75mm OD x 20.06mm L
|
NH
, Serial Range: -Y9N043084
|
| 13. |
614-12030
|
[8] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 14. |
811-8020
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 15. |
811-8030
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 30mm, Cl 8.8
|
CAS
, Serial Range: -Y9N043084
|
| 15. |
86512446
|
[3] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
, Start Serial: Y9N043085
|
| 16. |
9804262
|
[4] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 17. |
87039762
|
[124] |
SELF-TAP SCREW,Hex Wash Hd, 5/16"-18 x 5/8"
|
PA
Superseded by part number: 570821
|
| 18. |
245531
|
[3] |
WASHER,25.53mm ID x 31.24mm OD x 1.65mm Thk
|
NH
, Serial Range: -Y9N043084
|
| 19. |
495-21044
|
[8] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 20. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
, Serial Range: -Y9N043084
|
| 21. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
, Serial Range: -Y9N043084
|
| 22. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 24. |
58225
|
[1] |
WASHER,10.32mm ID x 31.8mm OD x 3.45mm Thk
|
NH
Superseded by part number: 87654824
|
| 25. |
825-1410
|
[2] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 26. |
825-2408
|
[3] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
, Serial Range: -Y9N043084 Superseded by part number: 86505868
|
| 27. |
832-46408
|
[4] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 28. |
9804278
|
[3] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 29. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 30. |
126-24
|
[1] |
WOODRUFF KEY,#15, 1/4" x 1"
|
CAS
Superseded by part number: 47471
|
| 31. |
87034858
|
[31] |
FILLER
|
PA
Filler, Optional
|
| 32. |
84324676
|
[1] |
GUARD
|
NH
RH
|
| 33. |
87053734
|
[1] |
GUARD
|
PA
LH
|
| 35. |
9804256
|
[6] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 36. |
322357
|
[6] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 40. |
84252192
|
[2] |
SUPPORT
|
NH
Superseded by part number: 47361794
|
| 41. |
350459
|
[4] |
CARRIAGE BOLT,Rnd Head, M10 x 1.5 x 50mm, Full Thd, Cl 8.8
|
ZED
|
| 42. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
