神钢零件查询(8DC8) - MITSUBISHI DIESEL ENGINE - K914 & K975 (1/79-12/06) (06-004) - AIR CLEANER (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
469 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-12. | VA3123006010 | [1] | AIR CLEANER ASSY FHG16 (M5) | |
| 1-11. | VA3193082010 | [1] | AIR CLEANER ASSY FHG16 (M6) | |
| 1-10. | VAME097305 | [1] | AIR CLEANER ASSY FHG14 (M7) | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY,A/CLNR |
| 2. | VA3123009800 | [1] | O-RING (FOR M7 ONLY) | |
| 2. | VA3123006170 | [1] | GASKET O-RING (FOR M5,M6 ONLY) | GASKET O-RING (FOR M5,M6 ONLY) |
| 3. | VA3123012700 | [1] | ELEMENT,A/CLNR (FOR M7 ONLY) | |
| 3. | VA3123011900 | [1] | ELEMENT,A/CLNR (FOR M5 ONLY) | |
| 3. | VA3193082500 | [1] | AIR FILTER | KOBELEMENT ELEMENT,A/CLNR (FOR M6 ONLY) |
| 4. | VA3123080500 | [1] | ELEMENT,A/CLNR INNER(FOR M7 ONLY) | |
| 4. | VA3193082400 | [1] | AIR FILTER | KOBELEMENT ELEMENT,A/CLNR INNER(FOR M6 ONLY) |
| 5. | VAME063304 | [1] | NUT | KOBNUT,WING (FOR M5 ONLY) |
| 6. | VA3123009700 | [1] | CLAMP (FOR M7 ONLY) | |
| 6. | VA3123006140 | [1] | CLAMP (FOR M5,M6 ONLY) | |
| 7. | VA3123009500 | [1] | BAFFLE (FOR M7 ONLY) | |
| 7. | VA3123006600 | [1] | BAFFLE (FOR M5 ONLY) | |
| 8. | VA3123060900 | [1] | CUP,DUST (FOR M7 ONLY) | |
| 8. | VA3123006700 | [1] | CUP,DUST (FOR M5 ONLY) | |
| 8. | VA3193082600 | [1] | CUP,DUST (FOR M6 ONLY) | |
| . . | VA3083030800 | [1] | PLATE,CAUTION | |
| 9. | VAME032915 | [1] | INDICATOR INDICATOR,DUST ELEC 635 (FOR M7 ONLY) | INDICATOR INDICATOR,DUST ELEC 635 (FOR M7 ONLY) |
| 10. | VA3083019700 | [1] | CAP,NIPPLE (FOR M5,M6 ONLY) | |
| . . | VAME032924 | [1] | BAND,CABLE (FOR M7 ONLY) | |
| 11. | VAME060217 | [1] | VALVE,VACUATOR (FOR M5 ONLY) | |
| 11. | VA3193082700 | [1] | VALVE,VACUATOR (FOR M6 ONLY) | |
| 12. | VAME033261 | [1] | CLAMP,HOSE (FOR M5 ONLY) | |
