| 1. |
86627870
|
[1] |
DRIVEN SPROCKET,15T
|
NH
Idler, 15T
|
| 2. |
86631123
|
[1] |
SPACER,12.95mm ID x 19.05mm OD x 27mm L
|
NH
3/4" OD x 1-1/16" Lg.
|
| 3. |
86636654
|
[1] |
ARM
|
NH
|
| 4. |
86705271
|
[1] |
SPACER,13.5mm ID x 25.4mm OD x 34mm L
|
NH
1" OD x 1-1/16" Lg.
|
| 5. |
66463
|
[4] |
BRACKET
|
PA
Superseded by part number: 87657039
|
| 6. |
138820
|
[2] |
FLANGED BEARING
|
GI
Bearing Superseded by part number: 86635012
|
| 7. |
47066
|
[1] |
BALL BEARING,35mm ID x 72mm OD x 19mm W
|
GI
|
| 8. |
47067
|
[1] |
RETAINER COLLAR,34.92mm ID x 56.33mm OD x 17.46mm Thk
|
MKT
Locking, Includes: Set Screw Superseded by part number: 47577188
|
| 9. |
86625655
|
[1] |
ARM
|
NH
LH
|
| 10. |
87051781
|
[2] |
SHAFT
|
NH
|
| 11. |
87042782
|
[1] |
TUBE,42 mm ID x 50.80 mm OD x 705 mm L
|
NH
LH Superseded by part number: 84526342
|
| 12. |
87051855
|
[1] |
MOUNTING PARTS
|
NH
Center Bearing
|
| 13. |
87042783
|
[1] |
TUBE,42 mm ID x 50.80 mm OD x 705 mm L
|
NH
RH Superseded by part number: 84526343
|
| 14. |
718013
|
[8] |
SPACER
|
NH
|
| 15. |
87043492
|
[2] |
ARM ASSY.
|
NH
|
| 16. |
86627115
|
[2] |
WEIGHT
|
NH
Counter Superseded by part number: 87644331
|
| 17. |
87515101
|
[1] |
CRANK
|
NH
RH
|
| 18. |
38767
|
[1] |
COLLAR,Lock, 31.9mm ID x 44mm OD 15.9mm Thk
|
GI
Locking, W/ Set Screw Superseded by part number: 47508396
|
| 19. |
84484181
|
[1] |
BALL BEARING,31.75mm ID x 62mm OD x 18mm W
|
GI
1-1/4" ID x 2.44" OD
|
| 19. |
84484181GV
|
[1] |
BEARING ASSY
|
MKT
Value, Ball Bearing
|
| 20. |
87758679
|
[2] |
FLANGED BEARING
|
PA
Superseded by part number: 87758678
|
| 21. |
87046282
|
[1] |
FRAME
|
NH
|
| 22. |
86606367
|
[4] |
SEAL,30mm ID x 42mm OD x 7mm Thk
|
NH
|
| 23. |
86606298
|
[4] |
BUSHING,30.12mm ID x 42.11mm OD x 42mm L
|
NH
|
| 24. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 25. |
66967
|
[4] |
SNAP RING,1.75", Int, #175
|
WIN
|
| 26. |
86050286
|
[9] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 27. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 28. |
9706693
|
[5] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
| 29. |
87337
|
[4] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
NH
|
| 30. |
86512420
|
[4] |
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 31. |
412085
|
[4] |
BOLT,Hex, M12 x 1.75 x 80mm, Cl 10.9
|
NH
|
| 32. |
393599
|
[1] |
SET SCREW,M10 x 25mm, Cl 12.9
|
NH
, Start Serial: Y9N043085
|
| 33. |
87364
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
NH
|
| 34. |
87051779
|
[1] |
SHAFT
|
NH
|
| 35. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
, Start Serial: Y9N043085
|
| 36. |
600083
|
[8] |
WASHER,19.3mm ID x 28.7mm OD x 1.36mm Thk
|
NH
3/4"ID x 1-1/8"OD
|
| 37. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 38. |
140046
|
[6] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 39. |
393698
|
[2] |
SCREW,FLAT, M10 x 25mm, Cl 8.8
|
ZED
|
| 40. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Clutch, Jaw, Serial Range: -Y9N043084
|
| 41. |
86629542
|
[8] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 42. |
412672
|
[3] |
NUT,Hex, M12 x 1.75, Cl 10
|
WIN
|
| 43. |
9626598
|
[4] |
NUT,3/4"-10, GB
|
PA
Superseded by part number: 280375
|
| 44. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 45. |
87038548
|
[1] |
WOODRUFF KEY
|
PA
|
| 46. |
87831
|
[1] |
WOODRUFF KEY,#D, 5/16" x 1 1/4", HT
|
GI
|
| 47. |
9807906
|
[4] |
BALL BEARING,0.7504" ID x 1.7805" OD x 0.61"
|
GI
Superseded by part number: 87029275
|
| 49. |
87040968
|
[1] |
BUSHING
|
PA
.752" ID x .875" OD x .750" Lg. Superseded by part number: 86573067
|
| 50. |
81541
|
[3/AR] |
WASHER,0.5" ID x 1.25" OD x 0.08" Thk
|
NH
|
| 51. |
87346700
|
[1] |
ARM
|
PA
Idler
|
| 52. |
87470734
|
[1] |
SPACER
|
PA
|
| 53. |
84173847
|
[1] |
SHAFT
|
NH
, Start Serial: Y9N043085
|
| 54. |
84493033
|
[2] |
CAP WASHER
|
NH
|
