现代零件查询10/13BOP-7 HARNESS(ADD LIFT)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
782 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
21HJ-72500
|
[1] |
FINGERTIP LEVER
|
|
| 2. |
21HW-72540
|
[1] |
SWITCH ASSY-LIFT ENABLE
|
|
| 3. |
21HJ-72580
|
[1] |
SWITCH ASSY-LIMIT
|
|
| 4. |
21HW-75321
|
[1] |
HARNESS-ADDLIFT LEVER
|
|
| 5. |
21HW-75330
|
[1] |
HARNESS-ADDLIFT SWITCH
|
|
| 6. |
21HW-75311
|
[1] |
HARNESS-ADDLIFT SOL
|
|
| 7. |
21HW-75350
|
[1] |
HARNESS-ADDLIFT LEVER EXT.
|
|
| 8. |
21HW-72550
|
[1] |
BRACKET-LIMIT SWITCH
|
|
| 8. |
21HW-72551
|
[1] |
BRACKET-LIMIT SWITCH
|
|
| 8. |
21HW-72550
|
[1] |
BRACKET-LIMIT SWITCH
|
|
| 8. |
21HW-72551
|
[1] |
BRACKET-LIMIT SWITCH
|
|
| 9. |
S543-080002
|
[7] |
CLAMP-TUBE
|
|
| 10. |
S681-230800
|
[2] |
GROMMET
|
|
| 11. |
S593-000752
|
[2] |
CLIP-HARNESS
|
|
| 12. |
S161-040206
|
[2] |
SCREW-CROSS R/ROUND
|
|
| 13. |
S411-040006
|
[2] |
WASHER-SPRING
|
|
| 14. |
S035-081526
|
[9] |
BOLT-W/WASHER
|
|
| 15. |
S035-082026
|
[2] |
BOLT-W/WASHER
|
|
