凯斯零件查询(RB564) - CASE IH ROUND BALER (7/07-1/14) (13.980[02]) - 2M WIDE PICKUP, ROLLER WINDGUARD, YCN174406 & AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
980 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84134986
|
[1] |
ARM
|
NH
LH
|
| 2. |
84252172
|
[1] |
ARM
|
NH
RH
|
| 3. |
87056826
|
[1] |
WINDGUARD
|
PA
|
| 4. |
47393437
|
[1] |
ROLLER,146mm OD x 2270mm L
|
NH
|
| 5. |
86603075
|
[4] |
FLANGE,Bearing, 52.01 mm ID x 95.3 mm OD x 8.7 mm
|
NH
|
| 6. |
325103
|
[2] |
BALL BEARING,25mm ID x 52mm OD x 15mm W
|
ZED
|
| 7. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 8. |
9671714
|
[6] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 9. |
87046828
|
[1] |
PLATE
|
PA
LH
|
| 10. |
87049395
|
[1] |
PLATE
|
PA
RH
|
| 11. |
86512447
|
[4] |
CARRIAGE BOLT,Short Square Neck, M10 x 60mm, Class 8.8
|
GI
|
| 12. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 13. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 14. |
87056822
|
[2] |
PIN
|
PA
|
| 15. |
374892
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
|
| 16. |
86603107
|
[4] |
NUT
|
PA
|
| 17. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 18. |
87051581
|
[2] |
CLAMP
|
PA
|
| 19. |
120100
|
[2] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 20. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 21. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 22. |
80702
|
[4] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 23. |
9804262
|
[2] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 24. |
133095
|
[2] |
SPACER,10.32mm ID x 15.85mm OD x 7.9mm L
|
NH
|
| 25. |
86621502
|
[6] |
CLIP
|
NH
|
| 26. |
84300312
|
[2] |
STOP
|
NH
|
| 27. |
87050886
|
[1] |
FINGER
|
PA
LH Superseded by part number: 87051603
|
| 28. |
87050884
|
[4] |
FINGER
|
PA
Middle Superseded by part number: 87051605
|
| 29. |
87050885
|
[1] |
FINGER
|
PA
RH Superseded by part number: 87051604
|
