Pos.	Part No	Qty	Parts name	Comments
1.	61HW-25040	[1]	PLATFORM & CARRIAGE WA	10BOP-7
1.	61HW-25041	[1]	PLATFORM & CARRIAGE WA	10BOP-7
1.	61HW-25040	[1]	PLATFORM & CARRIAGE WA	13BOP-7
1.	61HW-25041	[1]	PLATFORM & CARRIAGE WA	13BOP-7
2.	63HK-18101	[4]	LOAD R/BEARING(117.5)
2.	63HK-18111	[4]	LOAD R/BEARING(117.2)
2.	63HK-18121	[4]	LOAD R/BEARING(117.8)
2.	63HK-18131	[4]	LOAD R/BEARING(116.9)
3.	6600188000	[4]	SHIM(1.0T)
4.	6600187900	[4]	SHIM(0.5T)
5.	65FS-21380	[4]	BUSHING	10BOP-7
5.	65FS-21381	[4]	BUSHING	10BOP-7
5.	65FS-21380	[4]	BUSHING	13BOP-7
5.	65FS-21381	[4]	BUSHING	13BOP-7
6.	S111-120356	[4]	SCREW-SET HEX SOCKET
7.	S205-12100B	[4]	NUT-HEX
8.	65FS-21410	[4]	PLATE-BACK
9.	S037-122056	[1]	BOLT-W/WASHER
10.	61HW-26040	[1]	CARRIAGE ASSY-ADD. LIFT
11.	S403-08200B	[6]	WASHER-PLAIN
12.	S161-080306	[6]	SCREW-CROSS R/ROUND
13.	61HN-18400	[1]	WASHER
14.	61HW-18000	[1]	BRACKET WA
15.	S017-100606	[1]	BOLT-HEX
16.	S601-035004	[2]	RING-RETAINING
17.	61FY-18200	[2]	BEARING-CHAIN WHEEL
18.	S411-100006	[1]	WASHER-SPRING
19.	61FY-18800	[2]	BOLT-ANCHOR
20.	61FY-18810	[2]	BOLT-ANCHOR
21.	61FY-30570	[2]	CHAIN-FREE LIFT
22.	S206-161006	[8]	NUT-HEX
23.	S461-320202	[4]	SPUT PIN
24.	S411-080006	[6]	WASHER-SPRING
25.	61HW-18500	[1]	CLAMP WA-FREE CYL
26.	S411-140006	[2]	WASHER-SPRING
27.	S017-140356	[2]	BOLT-HEX
28.	S441-140006	[2]	WASHER-HARDENED
29.	63FG-18100	[1]	GUARD-CHAIN
30.	S471-800162	[1]	PIN-SPRING
31.	61HW-24611	[1]	PLATE-SIDE,LH
32.	61HW-24621	[1]	PLATE-SIDE,RH
33.	67FY-18610	[2]	SHIM(1.0T)
34.	67FY-18600	[2]	SHIM(0.5T)
35.	61HW-26100	[2]	PLATE-COVER	10BOP-7
35.	61HW-26100	[2]	PLATE-COVER	13BOP-7
36.	S035-082026	[8]	BOLT-W/WASHER	10BOP-7
36.	S035-082026	[8]	BOLT-W/WASHER	13BOP-7
