凯斯零件查询(RB564) - CASE IH ROUND BALER (7/07-1/14) (16.20) - BALE EJECTOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
429 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87040725
|
[1] |
RAMP
|
PA
Bale Superseded by part number: 87052857
|
| 2. |
86562970
|
[2] |
BUSHING,19.3mm ID x 41.61mm OD x 40.1mm L
|
NH
Rubber
|
| 3. |
647765
|
[6] |
SPACER
|
NH
Superseded by part number: 87022950
|
| 4. |
87037447
|
[2] |
PIN
|
PA
|
| 5. |
87029355
|
[2] |
SPRING,Compression, 2.14" OD x 19.9" L
|
NH
|
| 6. |
87028071
|
[2] |
ROD ASSY.
|
PA
|
| 9. |
86514369
|
[2] |
BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 8
|
ZED
|
| 10. |
9637417
|
[4] |
BOLT,Hex, 1/2" - 13 x 3 1/2", Gr 5
|
NH
|
| 11. |
86000020
|
[2] |
BOLT,Hex, 1/2" - 13 x 6", Gr 5
|
NH
|
| 13. |
87040148
|
[4] |
WASHER,19.81mm ID x 47.497mm OD x 6.35mm Thk
|
PA
|
| 16. |
280736
|
[2] |
NUT,5/16"-18, GC
|
NH
|
| 17. |
86521607
|
[4] |
FLANGE NUT,Flg, 1/2"-13, G5
|
NH
Superseded by part number: 86544265
|
