凯斯零件查询(RB564) - CASE IH ROUND BALER (7/07-1/14) (16.40[2]) - HYDRAULIC BALE EJECTOR, INDICATOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
272 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
264513
|
[3] |
SPACER
|
NH
|
| 2. |
87709396
|
[1] |
ANGLE
|
NH
|
| 3. |
86543545
|
[1] |
GUIDE
|
NH
|
| 4. |
28114
|
[1] |
U-BOLT
|
NH
|
| 5. |
80684
|
[2] |
LOCK WASHER,4.9mm ID x 8.48mm OD x 1.19mm Thk
|
NH
|
| 6. |
87304
|
[2] |
NUT,#10-24
|
BEL
|
| 7. |
87636759
|
[1] |
ANGLE
|
NH
|
| 8. |
87637406
|
[1] |
LEVEL INDICATOR
|
NH
|
| 9. |
87362
|
[2] |
WASHER,5/16" SAE
|
NH
Superseded by part number: 83918746
|
| 10. |
140041
|
[3] |
WASHER,M8 x 28mm OD x 3mm Thk
|
ZED
Superseded by part number: 9826296
|
| 11. |
140223
|
[2] |
WASHER,M13 x 25mm OD x 2mm Thk
|
ZED
|
| 12. |
87637939
|
[1] |
WIRE ROPE
|
NH
|
| 13. |
87674778
|
[1] |
ANGLE
|
NH
|
| 14. |
689986
|
[2] |
ANGLE
|
NH
|
| 15. |
696365
|
[1] |
SPACER
|
NH
|
| 16. |
510932
|
[1] |
PULLEY,50.01mm OD
|
NH
|
| 17. |
689987
|
[1] |
ANGLE
|
NH
|
| 18. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 19. |
120103
|
[2] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
Superseded by part number: 16043224
|
| 20. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 21. |
9671714
|
[1] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 22. |
86507311
|
[1] |
BOLT,Hex, M10 x 80mm, Cl 8.8
|
NH
|
| 23. |
87016
|
[1] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 24. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 25. |
43127
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 26. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 27. |
86619595
|
[1] |
DECAL
|
NH
|
| 28. |
47464
|
[1] |
CLAMP
|
PA
Superseded by part number: 418837
|
