凯斯零件查询(RB564) - CASE IH ROUND BALER (7/07-1/14) (18.19) - DIA KIT, TIRE, 21.5L X 16.1 10P Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
699 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84176094
|
[1] |
KIT
|
NH
Includes: Ref. 2 - 13 & Installation Instructions
|
| 2. |
87471253
|
[1] |
MOUNT
|
NH
LH
|
| 3. |
87482371
|
[1] |
MOUNT
|
NH
RH
|
| 4. |
0C
|
[2] |
ORDER COMPONENTS
|
NH
Wheel Hub , Includes: Ref. 14 - 25
|
| 5. |
87471265
|
[2] |
SPINDLE
|
NH
|
| 6. |
704588
|
[16] |
WHEEL BOLT,5/8" - 18 x 1-5/8"
|
GI
|
| 7. |
87997
|
[2] |
BOLT,Hex, 1/2" - 13 x 5", Gr 5
|
GI
|
| 8. |
412087
|
[8] |
BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd
|
BHB
Superseded by part number: 86639031
|
| 9. |
86641937
|
[2] |
SPACER,16.6mm ID x 31.75mm OD x 12.7mm Thk
|
PA
|
| 10. |
122432
|
[2] |
WASHER,17mm ID x 41mm OD x 6mm Thk
|
NH
Superseded by part number: 84058945
|
| 11. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 12. |
9636698
|
[2] |
NUT,1/2"-13, GB
|
NH
Superseded by part number: 88871
|
| 13. |
337475
|
[8] |
NUT,M12, Cl 10
|
BHB
|
| 14. |
87485977
|
[1] |
SPINDLE
|
NH
|
| 15. |
87491884
|
[1] |
HUB
|
NH
|
| 16. |
86516468
|
[1] |
ROLLER BEARING
|
ZED
Superseded by part number: 618023R91
|
| 17. |
714610
|
[1] |
FLANGE COVER CAP
|
NH
|
| 18. |
131526
|
[1] |
OIL SEAL
|
BEL
|
| 19. |
49029
|
[1] |
BEARING CUP
|
NH
Superseded by part number: 105497H
|
| 20. |
166258
|
[1] |
BEARING CONE,2.25" ID x 0.864"
|
NH
|
| 21. |
86516467
|
[1] |
BEARING CUP,65.08mm OD x 13.97mm W
|
ZED
|
| 22. |
80754
|
[1] |
COTTER PIN,3/16" OD x 1-1/2" OAL
|
NH
|
| 23. |
87569
|
[1] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
|
| 24. |
257163
|
[1] |
WASHER,25.4mm ID x 50.8mm OD x 4.17mm Thk
|
NH
|
| 25. |
280172
|
[1] |
SLOTTED NUT,7/8"-14
|
NH
|
| 26. |
87025710
|
[2] |
WASHER
|
PA
|
