凯斯零件查询(RB564) - CASE IH ROUND BALER (7/07-1/14) (18.42) - DIA KIT, HIGH MOISTURE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
837 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87725798
|
[1] |
KIT
|
PA
High Moisture, Includes: Installation Instructions
|
| 2. |
87582950
|
[2] |
ROLL
|
PA
|
| 3. |
87534300
|
[1] |
SUPPORT
|
PA
|
| 4. |
86637004
|
[2] |
SCRAPER BLADE
|
NH
|
| 5. |
9804261
|
[6] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 6. |
80702
|
[6] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 7. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 8. |
9804278
|
[6] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
87603065
|
[4] |
BEARING ASSY,40mm ID
|
PA
|
