凯斯零件查询(RB564) - CASE IH ROUND BALER (7/07-1/14) (19.03[05]) - KIT IDLER DECLUTCH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
643 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87298521
|
[1] |
KIT
|
MKT
Incl 2 - 11
|
| 2. |
103243
|
[4] |
DRIVEN SPROCKET
|
NH
|
| 3. |
86729275
|
[1] |
LOCK WASHER,5/8 0.634 CST ZND
|
BHB
|
| 4. |
140046
|
[3] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 5. |
280374
|
[1] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
|
| 6. |
280667
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 5/8" - 11 x 2 1/4", Gr 5
|
NH
|
| 7. |
65319
|
[4] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 8. |
86512497
|
[3] |
FLANGE NUT,M12 x 1.75, Cl 10
|
NH
|
| 9. |
86636724
|
[1] |
IDLER,101.6mm Idler Dia x 115.49mm OD x 37.31mm W
|
NH
|
| 10. |
87365
|
[1] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 11. |
9804270
|
[1] |
BOLT,Hex, M12 x 60mm, Cl 8.8
|
NH
|
