凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (05.100.02) - INITIAL STOCK LIST, LIST B Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
416 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84427925
|
[2] |
TOOTH
|
PLO
|
| 2. |
9843257
|
[2] |
CABLE
|
NH
|
| 3. |
84239208
|
[2] |
LAMP,12V, 28W
|
WIC
|
| 4. |
84239207
|
[2] |
TAIL LAMP,12V, 28W
|
WIC
|
| 5. |
86592671
|
[2] |
KNIFE SECTION
|
PA
|
| 6. |
87660576
|
[1] |
BEARING ASSY,40mm ID
|
NH
|
| 7. |
84266808
|
[1] |
BEARING ASSY,27.28mm ID x 47mm OD x 12.7mm W
|
NH
|
| 8. |
84350126
|
[1] |
CAM FOLLOWER,1/2" - 20 x 38mm OD x 54.5mm L
|
NH
|
| 9. |
84146982
|
[1] |
BEARING, ROLLER, CYL
|
NH
|
| 10. |
86977396
|
[1] |
POTENTIOMETER,3000 Ohm, 16 VDC
|
PA
|
| 11. |
87398962
|
[1] |
HUB,12.5mm ID x 47.42mm OD x 13.2mm L
|
PA
|
| 12. |
87013989
|
[1] |
KNIFE,445.8mm L x 38.1mm W x 3.4mm Thk
|
PA
|
| 13. |
617945
|
[1] |
KNIFE SECTION
|
NH
|
| 14. |
127434
|
[1] |
DISC,77.7mm ID x 146mm OD x 3.56mm Thk
|
NH
|
| 15. |
86594422
|
[1] |
SENSOR
|
NH
Tailgate, Net Wrap and Net Knife.
|
| 16. |
87052121
|
[1] |
GEAR
|
NH
|
| 17. |
9825943
|
[1] |
SENSOR
|
NH
Net Counter
|
| 18. |
87032323
|
[1] |
SPROCKET
|
PA
|
| 19. |
84259867
|
[1] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
PLO
|
| 20. |
9806864
|
[1] |
KNIFE,382mm L x 38.1mm W x 3.4mm Thk
|
NH
|
| 21. |
87011880
|
[1] |
SPROCKET,13T
|
ZED
Superseded by part number: 84401598
|
| 22. |
9806931
|
[1] |
IDLER GEAR,17T
|
NH
|
| 23. |
87609767
|
[1] |
LEAF SPRING
|
NH
|
| 24. |
86553396
|
[1] |
BEARING ASSY,30.23mm ID x 90mm OD x 30.2mm W, SQUARE BORE
|
NH
|
| 25. |
86977429
|
[1] |
BUSHING,44.62mm ID x 50.93mm OD x 22.2mm L
|
PA
|
| 26. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
|
| 27. |
86978603
|
[1] |
BEARING ASSY,45mm ID x 85mm OD x 22mm W
|
PA
|
| 28. |
86636892
|
[1] |
FLANGE
|
NH
|
| 29. |
412441
|
[1] |
ROLLER BEARING,40mm ID x 80mm OD x 21mm W, Round Bore
|
PA
|
| 30. |
664073R92
|
[1] |
BALL BEARING,38.1mm ID x 80mm OD x 21mm W
|
CAS
|
| 31. |
133941
|
[1] |
BALL BEARING,44.45mm ID x 84.99mm OD x 22mm W
|
NH
Superseded by part number: 84330073
|
| 32. |
86627923
|
[1] |
STRIP
|
NH
|
| 33. |
82017871
|
[1] |
RELAY,12V, 20A
|
BAS
Superseded by part number: 84411012
|
| 34. |
47535979
|
[1] |
STRIPPER
|
NH
|
